Help Center40KHZ Ultrasonic Ceramic Transceiver for Distance 10m
Related Products
-
Outdoor Waterproof Ultrasonic Sensor 12mm,14mm,16mm,18mm,24mmNegotiableMOQ: 1 Piece -
Ultrasonic Transducer Distance 10mNegotiableMOQ: 1000 Pieces
-
16mm 40KHZ Water Lever SensorNegotiableMOQ: 1000 Pieces
-
Ultrasonic Transmitter KS-A1640H12RNegotiableMOQ: 1000 Pieces
-
Ultrasonic Recepter KS-A1640H12RNegotiableMOQ: 1000 Pieces
Application
*Position measuring
*distance measuring
*Depth measuring
Specification
| Name | 40KHZ Ultrasonic transceiver |
| Size | 16*12mm |
| Frequency | 40KHZ |
| Using method | Dual use |
| Sensitivity | ≥-63db |
| Detectable Range | 0.5-16m |
| Max input voltage | 120VP-p |
| Capacitance | 2000± 20%PF at 1KHZ |
| Operating Temperature Rang | -30℃ to +85℃ |
| Quality control | ROHS & ISO 9001&SGS |
Dimention
Test circuit drawing
Other related ultrasonic transceiver
| No | Model | Center Frequency | Name |
| 1 | KS-P131000H6.5TR | 1.0MHz | Ultrasonic transceiver |
| 2 | KS-P201000H9.5TR | 1.0MHz | Ultrasonic transceiver |
| 3 | KS-P1040H07T/R | 40KHz | Ultrasonic transceiver |
| 4 | KS-P1640H12T/R | 40KHz | Ultrasonic transceiver |
| 5 | KS-A1040H08T/R | 40KHz | Ultrasonic transceiver |
| 6 | KS-A1240H9.5T/R | 40KHz | Ultrasonic transceiver |
| 7 | KS-A1440H09TR-2 | 40KHz | Ultrasonic transceiver |
| 8 | KS-A1640H10.5S | 40KHz | Ultrasonic transceiver |
| 9 | KS-A1640H12TR | 40KHz | Ultrasonic transceiver |
| 10 | KS-A1840H12TR | 40KHz | Ultrasonic transceiver |
| 11 | KS-A2425H13T/R | 25KHz | Ultrasonic transceiver |
Packaging &shipping
Packing
Small inner box and outside Carton box
custom packaging is also available
Shipping
DHL/UPS/FEDEX for samples or small orders
FOB China&CIF for bulk orders
Company informaiton
We specialize in producing Electro-acoustic components more than 10 years,we have strict quality contral systems,Our factory passed through ISO9000 and all of our products are up to ROHS standard.
Our main products are Buzzer(Piezoelectric buzzer / Electromagnetic buzzer / Mechanical buzzer / SMD buzzer ),Piezoelectric ceramic element , Condenser microphone , Ultrasonic sensor , Atomiztion piece etc.
Contact us
If you are interested about us,please feel free contact below,welcome to visit our factory
Skype: cosson_81
Tel:86-769-81885857
Molbile:+86-13433049023
