IPS-514V IP Smart Night Pro Array LED Bullet Camera Support ONVIF Protocol and POE P2P

US$ 170 - 180 MOQ: 20 Pieces

Key Specifications

Brand Name:

IPS

Model Number:

IPS-514V

Type:

Digital Camera

Shenzhen IPS Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Brand Name IPS

Model Number IPS-514V

Type Digital Camera

Style Other, Bullet Camera, Bullet Camera

Sensor Other, CMOS, CMOS

Technology NetWork

Special Features Other, support P2P

Specifications

1.720P low lux IP Camera
2..Real time transmission up to 25FPS@1MP
3.Two way audio support
4.H.264 compression

IPS-514V IP smart night pro 720P Array LED bullet camera support ONVIF protocol and POE P2P

Item		IPS-514V
	Device	1.0 Megapixel CMOS Sensor
	Size	1/3 inch
	Effective Pixels	1MP:1280*720
Min.Scene Illumination	Color	0.15 LUX(IR ON)
	B/W	Yes
	IR Sensitivity	Yes
	IR Cut	Yes
Lens	Lens	2.8-12mm lens
	Viewing Angle	22°-90°(Horizontal)
Linux System		Internal Linux system
Day/Nigh	IR distance	Array50 M
Functions	Motion Detection	Yes
	Electronic Shutter	1/5-1/15,000 sec
	BLC	Yes
	AGC	Auto
	White Balance	Auto
S/N Ratio	S/N Ratio	>50 dB
Video Compression	Compression	H.264
	Picture Resolution	HD: 1280*720
	Bit Rate	80 K~ 2.0 M bps
	Image Frame Rate	25 FPS
Audio	Compression	G.711
	Two way audio	support
Alarm I/O	Alarm I/O	1 channel in/out put
Casing	Mount Types	Wall Bracket
Network	Ethernet	Ethernet (10/100 Base-T),RJ-45 connector
	Protocol	TCP,UDP,IP,HTTP,FTP,SMTP,DHCP,DNS,ARP,ICMP,POP3,NTP,RTP, and RTCP
Software	Web Browser	Microsoft Internet Explorer 6.0 above
	SDK	SDK-H
	Security	Administrator password protection
Operating	Temperature	-30°~60°C
	Humidity	-10~85%
Power	Power Requirement	PoE (IEEE802.3af)
	Power Comsumption	12-13W (DC 12V,1A)
Physical	Dimension
	Weight
Approvals	Certification	CE ,FCC
