2.4" TFT LCD Module Display + PCB adapter + Touch Panel Screen
- 10000 Piece / Pieces per Month
- Shenzhen
- Credit Card
- Digital thermometer hygrometer used for travelling weather station pocket type
- Wireless Atomic Table Clock, Thermometer/Display In/Out Temperature, Blue/Green Backlight Selectable
- Weather Station Clock with Forecast/Desk/Digital Clock with in/Outdoor Temperature and Humidity
- Wired Weather Station/Desk/Digital Clock with In/Outdoor Temperature Display
- MAX / MIN Temperature And Humidity Automatic Memory Digital Thermometer Hygrometer
- Atomic Projection Desk Clock with Indoor Temperature and Big Character Display
Product Details
Brand Name: | CN | Model Number: | 2.4inch TFT lcd Module, 2.4 inches | Type: | Other, TFT, Glass touch scree |
Product Description
What is Specifications of our module ?
1.LCD screen + touch screen, with LCD & touch screen Controller Module.
2.ILI9325 240RGBx 320 a -Si 262K color TFT controller, ADS7843 compatible touch panel controller
3.16-bit data interface, Support 16 bit RGB565 format , can connect any 16 bit data bus
4.3.3v voltage regulator and 3.3V I/O voltage level tolerance
5.Standard SD card cage
6.2x20 Pin 2.54mm double row pin header interface
7.can be driverd by 8051 / AVR / PIC/DSP / FPGA and other low power controllers.
8.Module Size (L x W x H): 76 x 54 x 14mm
What is Advantages of our module ?
- Competitive factory price.
- Professional purchase team to serve you.
- All our products are checked by QC before shipping.
What is Refund & Replacement of our module ?
- We provide 30 days warranty for brand new goods only.
- If the item you purchase from us are not same as we promised, that is they don't work to manufacturers specifications, model mistake, simply return them to us for replacement or refund.
- If the items is defective, pls notify us within 3 working days on receiving it.
- Our sales representative will be here always serve for you.
Our Product Line:
Our Certifications:
What is Our Advantages?
- We are the professional supplier of the electronic components,located in the biggest components center of the world.
- We can provide the one stop purchase service.
- As a result, our clients can grow their business by focusing on their sales, ware-housing and distribution while we take care of their China buying.
- Client relationship and production management are the key factors that ensure successful China buying. Your account will be managed by our professional project managers.
- Fast delivery.
- Reasonable price.
Trade Terms:
- Payment: T/T (Bank Transfer), Western Union,PayPal,Alibaba Escrow.
- Delivery Time: 3-7days by DHL/Fedex/TNT,5-10days by EMS,15-30days by Air Mail.Ask the sales for details.
- MOQ: Sample order is accepted.
Why Choose us?
- We are in the largest electronic market of the world,we have a good working relationship with many supplier,we are focused on the electronic components and accessories.
- Alibaba Assessed Gold Supplier.
- The buyers from more than 100 countries and regions chose us!
How to Contact US?
- Send your Inquiry Details in the Below, Click "Send" Now!
Contact Us
- Shenzhen Sunshine Sea Technology Co., Ltd.
- Contact nameBetty Yuan
- Phone86-755-32872338
- AddressNo.1006,Yixiu Building 73,Xinqu Blvd,Longhua District Shenzhen,Guangdong
