DE series high speed cutting machine could meet the require for common cutting accuracy. It employs import synchronous belt for power driving, and work under high speed, convenient use, compatible with any CAD software. It is greatly welcomed by customers and widely applied for high accuracy cutting or plotting.
Knife tool
No. |
name |
application |
Note |
1 |
Special knife |
Used to cut materials within 2mm thick cutting materials:paperboard, Kraft paper, gray board,offset board and self-adhesive paper, etc.c |
Pen tool
No. |
name |
application |
Note |
1 |
Pen |
Drawing |
|
Specification
|
Model
|
GD1209 |
GD1509 |
GD1512 |
Effective cutting area |
1200*900mm |
1500*900mm |
1500*1200mm |
Configuration |
Special knife, pen
|
||
|
Way of fixing paper way
|
Vacuum absorbing
|
||
|
Driving material
|
Import synchronous belt
|
||
|
Cut materials
|
Red hard paper,plastic board,white board,kraft paper
|
||
|
Cutting way
|
Drawing by pen,half cutting,whole cutting
|
||
|
Cutting thickness
|
0.5-2mm |
||
|
Cutting precision
|
≤0.1mm |
||
|
Max speed
|
1000mm/s |
||
|
Working time and character
|
Continuous work, operating computer and cutting at the same time, linear high-speed transmission for data.
|
||
|
Transmitting port
|
International standards: parallel port/RSC232 serial port
|
||
|
Capacity of buffer area
|
Buffer area of large capacity, it can finish high-speed transmission for data at a time
|
||
|
Instruction set
|
AI,PDF,DXF,HPGL
|
||
|
Numerical control board
|
LTD, all-English operating menu
|
||
|
Driver
|
Step motor
|
||
|
Pen type
|
General signing pen, oil pen, ball pen
|
||
|
Main structure
|
Cutting platform,head,driving system,control cabinet,control micro computer,frame,vacuum pump
|
||
|
Voltage
|
AC 220V 50HZ |
||
|
Fuse standard
|
5A |
||
