The rapier loom is used to weave fabric with crude fibers (cotton, wool, hemp), chemical fiber and blending yarn etc. it is suitable for weaving thick fabrics.
Feature:
1)Beating system: adopt separating reed base, bilateral cam type beating instead of four-links beating, high increased the beating power.
2)Weft insertion system: adopt space crank connecting driver system, transmission device are installed in the closed box with the oiling device, suspended guiding teeth, left weft insertion, join in center, stable weft insertion, low warp broken rate
3)Transmission device: designed with the shortest transmission route, mostly decreased the transmission spare parts, and the main parts all adopt box type oiling, make the production and rapier more easier
4)Loom frame: Novel and reasonable design, make the production and installation convenient and reliable.
5)Outstanding cost-effective: compare with the expensive price of high-speed rapier loom, this machine with about 300RPM speed and reasonable price and operation cost, it is the ideal loom upgrade rom the low speed rapier loom.
Main data:
Reed width |
190cm,210cm, 230cm,280cm,360cm |
Speed |
270R.P.M(190cm) |
Yarn range |
Cotton 7 Ne-60Ne,wool 12Nm-100Nm Chemical fiber 100D-650D |
Shedding |
Mechanical(electronic)dobby, cam, electronic jacquard |
Diameter of warp beam |
Φ 800mmΦ680mm Φ600mm |
Diameter of rolling-up |
Φ 600mm |
Let off |
Mechanical, electronic |
Weft stop |
Piezoelectric ceramic sensor control weft stop |
Warp stop |
6 rows electric warp stop |
Color selection |
Mechanical or electronic |
Electric system |
Electronic board |
Control system |
PLS |
power |
2.2KW |
weight |
200kg-2500kg |
Overall size |
4706*1936*2220cm(230/90’’) |
Package:
