Draw-Texturing Machine

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New, New

Place of Origin:

Zhejiang, China

Model Number:

YJ1000V

Shaoxing Golden Gulf Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai Port China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Model Number YJ1000V

Automatic Yes

After-sales Service Provided Engineers available to service machinery overseas

Main datas:

1) Power: Whole power: 200.5kw

Effective power: 90.5kw

2) Spindle number: 240spindles (standard), 264spindles, 288spindles

3) Max. mechanical speed: 1,000m/min (W2 feed roll speed)

4) Twister type: Type 8 disc friction unit

5) First heater: biphenyl / 2,000mm

6) Second heater: biphenyl / 1,460mm

7) Cooling rail length: 1,100mm

8) Take-up roll diameter: Φ100mm

9) Feed roll diameter: Φ75mm

10) Oiling roll diameter: Φ75mm

11) Distance of both spindles: 110mm

12) Pitch: 1,440mm

13) Denier of fiber: 55 - 250 decitex

14) Take-up package: Φ250 x 250mm

15) Dimensions: 18,780 x 6,724 x 5250mm (Fixed creel)

Features:

The first heater (deforming heater) and the second heater (setting heater) adopt biphenyl air heating .The computer controls the heating and the temperature control. The precision of temperature control is ±1 °C, assure every spindle s temperature to be almost same .This is beneficial for even dying.
The machine has the features of simple structure, reliable transmission ratio, low noise level and easy technological adjustment.
The advanced designed electrical control system makes the operation simple, running reliable .Man-machine interaction can be realized by touching screen.
Two sides of this machine are relatively independent .The technology can be set separately. Different types and denier texturing yarn can be processed at the same time.

Product Photo:

Welcome to contact with us for further information!
