Home > Products > Signal lightning protection > 5V 5KA computer network devices price trade assurance
5V 5KA computer network devices price trade assurance
- 10000 Set / Sets per Month
- guangzhou
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Haide | Model Number: | HD-XNET |
Product Description
5V 5KA computer network devices price trade assurance
Electric surge protector of computer network signal is designed according to the standard of IEC electric surge protector. It considers fully that the electrode capacitance and distributed capacitance would lessen data signaling with small insertion loss and low output residual pressure. It has superior transmission performance, quick action, less insertion loss, RJ45 interface, 4 wires or 8 wires protection and 100M band width.
Model | HD-XNET |
Nominal working voltage Un | 5V |
Maximum continuous working voltage Uc | 6.8V |
Nominal discharge current In(8/20 us) | 2.5KA |
Maximum discharge current Imax(8/20 us) | 5KA |
1KV/us Voltage protection level Up | (X-X)≤33V |
(X-G)≤33V | |
Response time Ta | ≤1ns |
Operating temperature range Tup | -40℃ to +80 ℃ |
Series impedance R | 1Ω |
Insertion loss | ≤0.2dB |
Protection grade | IP20 |
Mode of connection | Connection in series |
Number of protection lines | 1,2,3,6 wire |
External dimension | 94*25*25mm |
Interface mode | RJ45 serial port |
Sheathing material | shielded metal aluminum |
1.. ISO9001&CE certificate &Test Report
2..Any inquiries will be replied within 24 hours.
3..Professional manufacture. Welcome to our website:http://gzhaidefanglei.cn.china.cn/
4..High quality, fashion designs, reasonable &competitive price, fast lead time.
5..OEM available.
6..After-Sale Service:
- Provide technical advice and maintenance knowledge and installation guide.
- Customers response time for one working time.
- All the products provide five year commitment to service.
- All the products are accompanied by China Pacific property insurance co;ltd.
7..Fast delivery
Sample order in stock, and 7-15 days for full production.
8..Terms of payment
You can pay for the order via: T/T, Western Union, PayPal &Money Gram.
9..Shipping
We have strong cooperation with DHL, TNT, UPS, FEDEX, EMS, China Air Port. You also can choose your own shipping forwarder.
10.Quality warranty
one year replacement, five years warranty.
network devices price trade assurance
