Multi Function 220V ul Power Strip Surge Protector Price Trade Assurance
US$ 10 - 16
MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Haide
Model Number:
HD-DCZ/TTN
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
380V 100KA Thunder Protection for Power Supply With Price Trade AssuranceUS$ 240 - 245MOQ: 10 Sets -
220V 40KA/20KA dc Power Lightning Arrester With Price Trade AssurnceUS$ 5 - 10MOQ: 10 Sets
-
4KG 750mm Copper Lighting Rod Price Trade AssuranceUS$ 5 - 10MOQ: 10 Sets
-
Black 2KV/1.5KV/1KV Lightning Protection 220v for Trade AssuranceUS$ 15 - 20MOQ: 10 Sets
-
Three Phase 320V Surge Discharger With Price Trade AssuranceUS$ 50 - 60MOQ: 10 Sets
Place of Origin
Guangdong, China
Brand Name
Haide
Model Number
HD-DCZ/TTN
Multi function 220V ul power strip surge protector price trade assurance
ul power strip surge protector price trade assurance
This series of product is applicable to the single-phase power line lightning and surge protection for the fine,universal sockets suitable for a variety of shape design of the power plug, is especially suitable for household electrical equipment simple lightning protection,automatic protection device,fault automatically off the grid,thereby protection the electronic equipment is working properly,can match network , telephone or television function,and with the work status indication lamp.
|
HD-DCZ/TTN |
||||
|
Model |
power supply lightning protection |
network lightning protection |
telephone lightning protection |
television lightning protection |
| Nominal working voltage Un | 220V | 5V | 180V | |
| Maximum continuous working voltage Uc | 275V | 6.8V | 200V | |
| Nominal discharge current In(8/20us) | 5KA | 2.5KA | 2.5KA | 2.5KA |
| Maximum discharging current Imax(8/20us) | 10KA | 5KA | 5KA | 5KA |
| 1 KV/υs Voltage protection level Up |
(X-X)≤33V | (X-X)≤220V | 400V | |
| (X-X)≤33V | (X-X)≤220V | |||
| Voltage protection level Up | 700V | |||
| Maximum intensity of backup fuse | 10A | |||
| Insertion resistance | ≤1Ω | ≤4Ω | ||
| Insertion loss | ≤0.2dB | ≤0.2dB | ≤0.2dB | |
| Number of guard wire | 1,2,3,6 wire | 2,3 wire | ||
| Message transmission rate Vs | 100Mbps | |||
| Bandwidth | 2MHZ | 860MHZ | ||
| Response time Ta | ≤25ns | 1ns | 1ns | 25ns |
| Operating temperature range Tup | -40°c to +80°c | |||
| Working order indication |
Green light means normal working,red light is fault indication |
|||
| Protection grade |
IP20 |
|||
| External dimension | 160X230X42mm | |||
| Sheathing material | flame retardant thermoplastic material | |||
| Mode of connection | universal jack | RJ45 | RJ11 | CATV/F |
1.. ISO9001&CE certificate &Test Report
2..Any inquiries will be replied within 24 hours.
3..Professional manufacture. Welcome to our website:https://img13.fr-trading.com/
4..High quality, fashion designs, reasonable &competitive price, fast lead time.
5..OEM available.
6..After-Sale Service:
- Provide technical advice and maintenance knowledge and installation guide.
- Customers response time for one working time.
- All the products provide five year commitment to service.
- All the products are accompanied by China Pacific property insurance co;ltd.
7..Fast delivery
Sample order in stock, and 7-15 days for full production.
8..Terms of payment
You can pay for the order via: T/T, Western Union, PayPal &Money Gram.
9..Shipping
We have strong cooperation with DHL, TNT, UPS, FEDEX, EMS, China Air Port. You also can choose your own shipping forwarder.
10.Quality warranty
one year replacement, five years warranty.
ul power strip surge protector price trade assurance
