Help CenterRiding Type Paddy Rice Transplanter
Related Products
Specifications
1.Single wheel drive2.Easy to operate
3.Adjustable hill spacing (planting distance)
4.Low running & maintenance cost
|
We are manufacture of the rice transplanter machine 6 rows, 8 rows and 10 rows. Common type, electronic start engine type and hydraulic type optional. Model:2ZT-6300, 2ZT-8300, 2ZT-8238, 2ZT-10238 etc. The detailed information as follows:
FEATURES |
|
| ADVANTAGES |
|
Item |
Rice Transplanter specification |
Dimensions (Length x Width x Height) (mm) |
2415 x 2165 x 1300 |
Overall machine weight |
250Kg~400Kg |
Adopted power |
170 Air cooled Diesel engine (3.23kw @ 2600rpm); 175 Air cooled diesel engine(4.4KW@2600rpm); 178F/E Air cooled diesel engine (5.5KW@3000rpm) |
Transplant part |
Single wheel drive strip plate profiling |
Work part |
Split Stirling Crank and close rod transplanting part |
Row numbers (row) |
4/6/8/10 |
Row distance (mm) |
238 / 300 |
Plant spacing of transplants (mm) |
120-140;140-170; 120-140-170-190-210 |
Rice planting depth (mm) |
The lifting rod is stepless adjustment |
Working speed per row (m/s) |
0.35 – 0.58 |
Running speed on rod (km/h) |
7.8-10.7 |
Working capacity (mu/h) |
2~5 |
The maximum width of separating needles entering into seedling discharge gate |
17 |
Single trip transverse dividing seedling sequence (time) |
14 |
Paddy field impeller |
OD is 680mm |
Run on road |
OD is 705mm |
The maximum angle of road wheel left and right turning |
600 |
