Design Fin Tube Steam Heat Exchanger

Design Fin Tube Steam Heat Exchanger thumbnail-1
Design Fin Tube Steam Heat Exchanger thumbnail-2
Design Fin Tube Steam Heat Exchanger photo-1
Design Fin Tube Steam Heat Exchanger photo-2
US$ 10 - 10,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
GELE
Structure:
Tube Heat Exchanger
Contact Supplier Request Quote Chat Now
Guangzhou Gele Heat Energy Equipment Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
GUANGZHOU
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name GELE
Structure Tube Heat Exchanger
Specifications

air heat exchanger for rotograuve printing machine
1.good heat conduction
2.long service life
3.high efficiency

 Air heat exchanger for rotograuve printing machine
Work pressure: 2.0MPa

 Work temperature: 300

 Making standard: GB/T14296-93
The specification is according to the customers' requirements

 surface tube number effective height   overall height 2 rows  4 rows  6 rows  8 rows  Dia of connecting tube  effective tube length
 4  152  228  160  180  260  330  48X3.5  300-2500
 6  228  304  160  180  260  330  48X3.5  300-2500
 8  304  380  160  180  260  330  48X3.5  300-2500
 10  380  456  160  180  260  330  48X3.5  300-2500
 12  456  532  160  180  260  330  48X3.5  300-2500
 14  532  608  160  180 260  330  60X4  300-2500
 16  608  684  160  180  260  330  60X4  300-2500
 18  684  760  160  180  260  330  60X4  300-2500
 20  760  836  180  200  260  350  75X4  300-2500
 22  836  912  180  200  260  350  75X4  300-2500
 24  912  988  180  200  260  350  75X4  300-2500
 26  988  1064  180  200  260  350  75X4  300-2500
 28  1064  1140  180  200  280  350  75X4  300-2500
 30  1140  1216  210  200  280  350  90X4.5  300-2500
 32  1216  1292  210  220  280  350  90X4.5  300-2500
 34  1292  1368  210  220  280  350  90X4.5  300-2500
 36  1368  1444  210  220  280  350  90X4.5  300-2500
 38  1444  1520  246  260  280  350  110X4.5  300-2500
 40  1520  1596  246  260  280  350  110X4.5  300-2500
 42  1596  1672  246  260  280  350  110X4.5  300-2500
 44  1672  1784  246  260  280  350  110X4.5  300-2500
 46  1784  1824  246  260  280  350  110X4.5  300-2500



Design Fin Tube Steam Heat Exchanger



Design Fin Tube Steam Heat Exchanger

Design Fin Tube Steam Heat Exchanger





Making Process





Application

Design Fin Tube Steam Heat Exchanger

Fair



Design Fin Tube Steam Heat Exchanger



Factory
