2 Megapixel 1080p Indoor Embedded PTZ IP Camera

Name: 2 Megapixel 1080p Indoor Embedded PTZ IP Camera
Brand: HUISUN / OEM
SKU: 130191525
Availability: InStock

Shenzhen HUISUN Technology Co., Ltd.

US$ 1 - 200 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

HUISUN / OEM

Model Number:

DE226NT-WN20IB-W1

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB shenzhen & EXW

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name HUISUN / OEM

Model Number DE226NT-WN20IB-W1

Type Digital Camera

Style Dome Camera

Sensor Other, CCD, 1/3 CCD

Technology Pan / Tilt / Zoom

Special Features Waterproof / Weatherproof

Specifications

1. 1/3 CCD sensor /1080P
2. 20 X Optical zoom
3. 360 degree continuous rotation
4. Optical Wiper and auto tracking design

Main Feature:

1. First Patent of Out Cool Air Circulation to Sink the Heat Technology(Patent No.ZL201220269676.7)

2. First Patent of Video Analysis Light-adjustment Technology .(Patent No.201110089768.7)

3. Patent external wiper design, to make sure the HD image is clearer all day.(Optional configuration).

4. Built in power with wall mounted bracket design, making it more convenient for maintenance on site.

5. Auto tracking function for unman surveillance

Technical parameters
Model	DE226NT-WN20IB-W1
Image Sensor	1/3" CCD
Definition	1080P (2.0 Megapixel)
Focus length	Optical 20x Zoom
communication protocol	PAL/NTSC
Day/night mode	Automatic/multicolour/monochroma(ICR)
Focus mode	Automatic/manual
S/N	> 50dB
BLC	0 ~ 20
White banlance	Automatic/manual
Electronic shutter	Off / On (Max 42dB)
AGC	Auto / Shutter PRI / Iris PRI / Manual
Min illumination	Color: 0.01Lux(F1.6.30IRE) Black/White: 0.02Lux (F1.6.30IRE)
Video input	Connector
Speed dome camera
Pan speed		Pan speed 0.01°/s~360°/s
Tilt speed		Tilt speed 0.01°/s~120°/s
Rotation		Pan :0~360° continuous rotation tilt:-10~90° auto flip
Preset		256 preset (chinese tilt)
Auto scan		8 groups, settable boundaries and scan speed
Auto cruise		8 groups each with 32 presets with settable time interval
Password protection		Support
Video analysis		support
Auto track		Support (Optional)
On-line update		support
Timing Action		RTC clock design for timing events during the whole week
Wiper		support (Optional)
Alarm		7 input 2output ( Optional)
Heat dispersion		Out Cool Air Circulation to Sink the Heat Technology
Supply voltage		DC12V+10%
Levels of protection		IP66/Level2 lightness protection,4000V prvent thunderbolt surges design
Working temperature		-35℃-+55℃
Working humidity		<90% No condensation
Consumption		Max 38W
OSD Menu		Chinese/ English
Weight		4.8 kg
Accessory		Wall -mount bracket DC 12 Power
