1. Introduction
Manual wheelchair ramp can be applied for low-floor city bus, and it is installed under the side of passenger door’ step. When the bus arrives at bus station, the driver unlocks the front cover and pulls the platform of the ramp out. After the platform reaches final position, rear-end of the ramp will be raised to eliminate height of threshold of passenger door so as to ensure rear-end of the platform level up to the bus floor, convenient for wheelchair to access the bus. After the wheelchair gets on the bus, retract the platform manually.
The manual wheelchair ramp is fixed with the frame under the floor of the passenger door by 4 brackets. These brackets are composed of 16 bolts (M10*20) and nuts and spring washers and flat washers (the diameter is 10mm).
2. Technical Parameter
Model |
Drive mode |
Platform net size (L*W) |
Installation |
MWR-1 |
Manual |
1054*988(Standard) |
Installed under the passenger door, rear-end of ramp will raise to eliminate height of threshold of passenger door and level with bus floor. |
MWR-2 |
Manual |
1208*800(Europe) |
Model |
Platform Net Size (A×B) |
Overall Width (C) |
Overall Height (D) |
Overall Length (E) |
Loading Capacity |
Own Weight |
MWR-1 |
1054*988 |
1124 |
62 |
1416 |
350 Kg |
40 Kg |
MWR-2 |
1208*800 |
936 |
60 |
1556 |
350 Kg |
40 Kg |
3. Installation Requirement
Min space required to install ramp unit: mm
Model |
Net Width of Door |
Accessible Width Under Vehicle |
Accessible Height Under Vehicle |
Accessible Depth Under Vehicle |
Remark |
MWR-1 |
998 |
1090 |
200 |
1415 |
- |
MWR-2 |
810 |
940 |
200 |
1550 |
|
Packaging Details:
1) Internal packaging:be packed air bubble film inside first
2) External packaging:be packed in wooden cases
Delivery and shipping Details:
1)Usually be shipped by maritime transport
2)if it is landlocked countries, generally
land and sea transport.
3)15—30 days after confirmation of the purchase order
we use wooden case pack for wheelchair lift,wheelchair ramp and swivel seat
We use Carbox for Electric step,wheelchair restraint system
WL-UVL Series Wheelchair Lift
EWR series Electric Wheelchair Ramp
FMWR series Manul Wheelchair Ramp
X-801-1 Wheelchair Restraint System
if you are interested in our products, we will provide satisfactory service for you!
1)- One year warranty for whole machines.
2)- Providing free quick-wear part.
3)- Low charge for continue maintenance when warranty is expired.
4)- Exclusive engineer support at any time.
5)- We can provide free training to end-users
6)- 24hours online services
