Xinder FMWR-A Manual Folding Bus Wheelchair Ramp
- 1000 Piece / Pieces per Month
- SHANGHAI
- T/T Credit Card
- Bus Engine Part YBM866005 491Q-ME-1105020 Gasoline Fuel Filter
- High Quality Kinglong Bus Part 261500177 Emergency Valve
- Wholesale King Long Bus Parts Auto Parts Door Pump Pull Rod
- Wiper Motor for Higer Bus
- 37VAA-75100-AMP High Braking Light suitable for business truck Bus
- Universal bus parts MB-QZ1 Door pump for Yutong Bus
Product Details
Type: | Flooring | Certification: | ISO9001:2000 | Size: | 885*920 |
Material: | mainly aluminum and iron | OEM No.: | OE SPEC | Bus Model: | Dennis Ankai Kinglong Higer Yutong |
Place of Origin: | Jiangsu, China | Brand Name: | xinder | Model Number: | FMWR-1A |
Product Description
1. INTRODUCTION
This FMWR-1A fold manual wheelchair ramp can be applied for low-floor city bus, and can be installed on the vehicle floor.
It also should be controlled manually and the material of base is aluminum. It is installed on the vehicle floor, when need it, you just unfold the ramp. There will be a slope which can help the disabled get into/out of vehicle.
The operation of manual wheelchair ramp is easy, simple, independent and wholly manual, because it doesn’t need to connect with vehicle electric system. This ramp takes no space of vehicle. Moreover, the platform of ramp and the floor of vehicle are at the same level, so there is no effect for passengers
2. ADVANTAGES
Interlock system: there is magnet in the ramp, and there is proximity switch at the left of ramp, so that the driver can know whether the ramp is under performance status. When the ramp is used, the vehicle door can not be opened, and there will be warning signal at the instrument desk.
Easy installation: this ramp has been assembled before delivery, so the only thing that customer need to do for installation is to drill holes with right size, and then mount the ramp according to installation instruction, which is easy and simple. Ramp working platform adopts anti-skidding honeycomb board, so that this ramp has many advantages, such as light, powerful loading capacity, strong non-corrodibility and so on.
Low installation requirements: this ramp is mainly applied for low-floor city bus. It is installed on the vehicle floor, and it doesn’t take up any room of vehicle when it isn’t used. Meanwhile, there is no requirement for height of vehicle floor.
Model Platform Net Size (A×B) Overall Width (C) Overall Height (D) Overall Length (E) Effective height(F) Platform weight
3. DIMENSIONS
4.INSTALLATION REQUIREMENTS
5. OPTIONAL PART: Aluminum Board
Standard folded ramp face: smooth face as Figure 1 shows.
Optional folded ramp face: honeycomb-board face is as Figure 2 shows.
Packaging Details:
1) Internal packaging:be packed air bubble film inside first
2) External packaging:be packed in wooden cases or carton box
Delivery and shipping Details:
1)Usually be shipped by maritime transport or air transport
2)if it is landlocked countries, generally land and sea transport.
3)15—30 days after confirmation of the purchase order
Usually we use wooden case pack for wheelchair lift,wheelchair ramp and swivel seat
Carbox for Electric step,wheelchair restraint system
Xinder-Tech was established in 2001 and ISO/TS 16949 certified
We are the leader of mobility in China and our products has taken up 90% of Chinese market.
Products has been exported to over 50 countries, such as France, Italy, New Zealand, Finland, Spain, Brazil, Costa Rica, Korea, Australia, Austria, Malaysia, Bulgaria, Israel, Philippines, Iran, India, Poland, Denmark, Kuwait, Malta, Mauritius, South Africa, Saudi Arabia, Chile, Thailand, Turkey, US, Russia, Mexico, Japan, Vietnam, Armenia, Singapore, Bahrain, Norway, Indonesia…
CE certified products:
WL-D Series wheelchair lifts
WL-UVL series wheelchair lifts
WL-T series wheelchair lifts
ES series electric steps
FMWR series manual wheelchair ramps
EWR series electric wheelchair ramps
ISO certified product: Wheelchair restraint system
WL-D series Wheelchair lift for Van
BMWR series Wheelchair ramp for Van
S-LIFT swivel lifting seat
ES Series Electric step
WL-UVL Series Wheelchair Lift
EWR series Electric Wheelchair Ramp
FMWR series Manul Wheelchair Ramp
Wheelchair Restraint System
