Piezoresistive Sensor

Caution:

1.Use of chemicals:Synthetic resins such as polycarbonate are used in the potentiometer.therefore,care must be taken not expose the resistor to thick atmosphere of ammonia,amins ,alkali solution,aromatic hydrocarbon,ketenes,esters,halogeneous hydrocarbon,ketenes esters,halogeneous hydrocarbons,ets.

2.When soldering ,avoid using water-soluble flux,othrewise,itmight cause and adverse effect on molding material and metal.

3.Although electric poles of resistors are generally formed by silver printing,we provide carbon coating over the silver poles to enhance reliablility against ntact us if you wish to use the part in a low residual resistance state.

Product Type & Condition :

1. Because of the fluctuant sales situation. the stock parts are always changing and the stock list cannot be promptly updated . So,please consult the stock situation when you inquire.

 Buyer Reading:

1. Please confirm receipt of products if the items you received , and if the goods was damaged please contact us immediately. send the photo to us that we can check and give you best solution .

2. We only guarantee Delivery in time but we couldn't control the express delivery time. Our related sales person will be responsible to send the AWB for the delivered goods in the next workday. you can check the AWB in the website which we send to you. For the AWB you also can call to the local branch of the express company in your company.

 Item No.: WDJ-22  piezoresistive sensor

Feature

1)Flux builded-up prevention is taken through inserting molding around the resistor with resin.

2)A large variety of products lined up to support various applications.

3)Miniature design for Audio applications.

4)Long life type available

Electrical characteristics

Total rotation angle :260°

Operating force :20-200gf.cm

Shaft stop strength :3kgf.cm/min

Switch working angle/stroke: 30  ±10°

Switch working torque /force:50-300gf.cm

Rated dissipation:0.125w   0.06w

Rated voltage :200V   150V

Insulation resistance :DC500V   500M Ω

Voltage proof:AC500V,1minute

Switch contact resistance:less than 20m Ω

Switch ratings:12VDC  1A

Mechanical endurance :10000cycles

Switch life:10000times

Resistance taper:A /B/ C

All resistance below

B101-100Ω

B501--500Ω

B102--1k

B202--2k

• B502--5k

  B103--10k

  B203--20k

  B503--50k

  B104--100k

  B204--200k

  B254--250k

  B504--500k

  B105--1M
