PCB Mount Hall Effect DC AC Pulse Turbility Current Transducers / Sensors RCB41D Series, Current Signal Detector

Name: PCB Mount Hall Effect DC AC Pulse Turbility Current Transducers / Sensors RCB41D Series, Current Signal Detector
Brand: ROCKET
SKU: 130154099
Availability: InStock

PCB Mount Hall Effect DC AC Pulse Turbility Current Transducers / Sensors RCB41D Series, Current Signal Detector thumbnail-1

PCB Mount Hall Effect DC AC Pulse Turbility Current Transducers / Sensors RCB41D Series, Current Signal Detector photo-1

Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

ROCKET

Model Number:

RCB41D series

Contact Supplier Request Quote Chat Now

Ningbo Huayu Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name ROCKET

Model Number RCB41D series

Usage Magnetic Sensor

Theory Hall Sensor

Output Analog Sensor

Hall effect current sensor module: RCB41D series

Closed loop Hall effect current sensor RCB41D series are for the real-time precision galvanic isolation measurement of the current: DC, AC, pulse and irregular wave current between the primary circuit and the secondary circuit.

Performance parameters

Electric parameters									Features 1. Magnetic balance (closed loop) 2. According to UL 94-V0 requirements 3. RoHS and CE certificated Superiorities 1. Excellent accuracy, good linearity 2. Low thermal drift 3. Wide bandwidth 4. Fast response 5.High immunity to external interference 6. Good overload capability 7. Low inductance Applications 1. VFC in household appliance 2. AC variable-speed drive 3. UPS 4. Converter / inverter 5. Industrial power supply 6. Solar power and wind power 7. Electrical application
Ipn	Nominal RMS current	5A	10A	15A	20A	25A	30A	50A
Ip	Measuring range	15A	30A	45A	60A	75A	90A	120A
Vsn	Output voltage @ Ipn	5V
Kn	Turns ratio	4:2000	3:3000	2:3000	1:2000	1:2500	1:3000	1:3125
Rm	Load resistance Rmax	≥10kΩ
Vc	Supply voltage	±12V~±15V
Ic	Current consumption	12mA+output current
Vd	Withstand voltage	3kVrms/50Hz/min
Dynamic parameters
X	Accuracy @Ta=25°C	±0.7% FS
εL	Linearity @Ta=25°C	±0.2% FS
VO	Offset voltage @Ta=25°C	±20mV
VOT	Thermal drift	≤±0.5mV/°C
Tr	Response time	≤1us
BW	Bandwidth	DC~100kHz
di/dt	Following accuracy	>50A/us
General parameters
Ta	Operating temperature	-40~+85°C
Ts	Storage temperature	-40~+90°C
W	Weight	12g
Standards		EN50178:1998, ISO9001

Dimension (mm)

Connection

Notice

1. Please connect according to the dimension drawing in which defining the current flowing direction and the function of the PIN.

2. The temperature of the primary busbar can't be over 100°c.

3. We can also develop and manufacture sensor depending on customers' requirements. Welcome to communicate with us if you are in this kind of demand.

Application cases

Certifications (ISO,CE,RoHS)
