Home > Products > Smokehouse > QXZ2/2 Smokehouse
QXZ2/2 Smokehouse
US$ 20,000 - 23,000
/ Set
1 Set(Min. Order)
- Tianjin
- T/T
You May Like
-
QXZ1/2 Smokehouse
-
500kg/h Smokehouse Smoke Oven for Sausage Fish
-
Industrial Fish Pork Sausage Smoke House Smoke Oven 500kg per Time
-
500kg EachTime Fish Chicken Sausage Smoke Oven Smokehouse for Fish
-
500kg EachTime Fish Sausage Smoke Oven Smokehouse for Fish
-
500kg per Time Industrial Fish Sausage Smoke House Smoke Oven
Product Details
| Condition | New | Type | Sausage | |
| Application | Smoking Meat | Automatic Grade | Automatic | |
| Production Capacity | 500kg/time | Place of Origin | Hebei, China | |
| Brand Name | CHENGYE | Model Number | QXZ2/2 | |
| Voltage | 380V | Power(W) | 10kw | |
| Dimension(L*W*H) | 2530*2260*3278 | Weight | 2500kg | |
| Certification | CE Certificate | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Product Description
Structure: Smokehouse QXZ2/2 composed of smoking house, steam heating system, smoke system, smoke evacuation system and control system. Adopted excellent SUS304 stainless steel.
Control: Computerized automatic control, big touch screen. Parameters can be shown in one control interface. 100 recipes could be restored.
Feature:
- 1. The machine is with cooking, smoking, steaming, drying functions for meat processing. Besides, other functions such as cooling, baking, spraying etc.
- 2. Unique smoking generator system.
- 3. Advanced inner circulation smoke generating system.
- 4. Smokehouse YX2/2 has been made special improvement, so the machine with excellent smoking, drying function, it is quite fit for smoking products such as Ha’Erbin red sausage.
Technical Data:
Type | Capacity (kg) | External Dimension (mm) | Power (kw) | Steam Pressure (MPa) | Max High Pressure Temperature (℃) | Max Low Pressure Temperature (℃) | Air Consumption (kg/h) | Weight (kg) | Trolley (set) |
QXZ2/2 | 500 | 2530×2260×3278 | 10 | 0.4~0.8MPa | 100 | ≤100 | 140 | 2500 | 2 |
