Silicon Powder Jet Mill High Quality Powder Machinery

Silicon Powder Jet Mill High Quality Powder Machinery photo-1
US$ 10,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, impact mill
Product Type:
Other, impact mill
Payment & Shipping
Payment Methods:
Port of Shipment:
guanghzhou
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, impact mill
Product Type Other, impact mill
Place of Origin Sichuan, China
Brand Name JSDL
Model Number JSDL-CJM
Voltage 380V
Power(W) 0.75KW
Dimension(L*W*H) subject to custmer`s requests
Weight different models different weight
Certification CE,ISO
Warranty 12 month
After-sales Service Provided Engineers available to service machinery overseas



  Silicon Powder jet mill high quality powder machinery

Silicon Powder jet mill high quality powder machinery



Product Description



Working principle:

impact pulverizer is adopting The high-speed rotation body’s hammer, vane, barred body to impact the crushed materials, with help of the direct impact of the materials in the rotation body,high –speed impact of the high-speed materials ,shear grinding from the rotaion body and stator or the wall pressure, to achieve the pruposeofultrafine crushing for the materials.

Characteristics of the equipment:

1, apply Ultra-fine grinding process of soft objects whose Moh's hardness is under 3.5

2, the crushed size range is finer than the normal equiement, High speed impact mill machinery is built in the  Efficient turbine classifier

3, can eject the standard fine powder on time to avoid  overfine, can produce the product with Defect distribution steep,the product fineness is adjustable d97=10~74um

4 The crushing chamber is equipped with automatic slag discharge device which can eject the Hard grinding particles and impurities itselft.

5 can scatter the united materials

6 Mass flow of air means the cooling grinding,Can be used for heat sensitive material processing ,No accumulation problem

7 Totally Closed negative pressure operation,No dust pollution



technical parameters:

model

Max feed size

discharging size

production capacity



Installed power

JSDL-CJM66

<2-5mm

1-100um

60-300kg/h

10-18kw

JSDL-CJM132

<2-5mm

1-100um

250-800kg/h

15-37kw

JSDL-CJM180

<2-5mm

1-100um

450-1000kg/h

25-54kw

JSDL-CJM330

<2-5mm

1-100um

850-2000kg/h

35-86kw

JSDL-CJM660

<2-5mm

1-100um

2100-4500kg/h

60-182kw

JSDL-CJM1500

<2-5mm

1-100um

3100-8000kg/h

120-360kw



Our Services

 we company relied on a military factory, what we offer are the best quality product.

here is the patent we had got:

Silicon Powder jet mill high quality powder machinerySilicon Powder jet mill high quality powder machinerySilicon Powder jet mill high quality powder machinerySilicon Powder jet mill high quality powder machinery
