micron quartz Powder Classifier/air classifier mill/jet milling classifier
working principle:
the raw material is crushed by jaw crusher to the size required, then elevated into a hopper from which the material is transported through the electro-magnetic vibrating feeder evenly and continuously into the grinding chamber for powder-processing.
The rollers oscillate outward to press the ring because of the centrifugal force and the shovel scoops up the materials, send to the middle between the ring and rollers to accomplish the grinding.After grinding, the rough materials will be recycled by the air from the fan back into the grinding chamber for regrinding and the fine powders are blew into the cyclone and poured out through the output-powder pipe as the final products.
1. High efficiency and low energy consumption.
2. Accept different raw material size.
3. Dust extraction is up to the national relative standard.
4. Good stability and free from noisy pollution.
5. Good sealability.
well done powders:
techinical data:
Type/data/name | JS1410 | JS2115 | JS2615 | JS2715 | JS3016 | JS3216 | JS4116 |
Max feed size | 10-15 | 10-20 | 10-20 | 10-20 | 10-25 | 20-25 | 20-30 |
Raw material size | 0.125-0.044 | ||||||
Gross output(T) | 0.5-8 | 1-18 | 1.5-20 | 2-28 | 3-35 | 6-50 | 6-66 |
Center shift speed(r/min) | 280 | 160 | 162 | 162 | 160 | 140 | 103 |
Inner diameter of grinding ring(mm) | 435 | 630 | 780 | 820 | 910 | 970 | 1280 |
Mainframe power(kw) | 7.5/6 | 15/8 | 18.5/8 | 22/8 | 30/8 | 37/4 | 75/4 |
Fan power(kw) | 5.5/2 | 11/4 | 15/4 | 1835/4 | 22/4 | 30/4 | 55/4 |
Analyzer power(kw) | 1.1/2 | 2.2/6 | 2.2/6 | 2.2/6 | 2.2/6 | 5.5/4 | 7.5/4 |
we have professional sales team for pre-sales and after-sales services, also we will send engineer to your factory if you need.
We believe that our perfect products and excellent services will establish a win-win business relationship with you.
Chengdu Our Trading Co.,Ltd is a trade and industry integrated company which established in 2008 with abundant exporting experience. With the company developed, we have 2 factories, one is located in Chengdu and another is in Mianyang.
Our main products are micronizer jet mill, micronizer impact mill, air classifier, inter gas protective equipmentetc.
patent:
workshop:
website:
tel: 028-61318297
Skype: wu.yao5
any question welcome to contact me !
