Universal Data Logger

Specifications

Universal Data Logger

FEATURES:

• Used latest micro controller based technology for better accuracy
• 8 Channel fixed input for all thermocouple, J, K, R, S, T, E, B, N programmable by user & RTD (PT-100), 4-20mA, 0-10 VDC factory settable
• Easy on-line field calibration by front panel membrane keypad
• Field programmable channel scan time 1 to 59 sec., Logging interval 1 to 9999sec&Printing Interval 5 to 9999 sec.
• Field programmable Delay time 1 to 99 sec. for Relay Output
• Optional RS-232 / RS-485 Modbus Serial Port
• Optional Parallel /USB Printing Port

APPLICATIONS:

• ISO Certification records, Validation process certifying
• Pharmaceutical process validation with graph & excel report in Autoclaves
• Online profile recording for Oven & BOD, Incubator, Humidity Chamber
• Winding temperature of generators, Bearings, motors, transformers
• To know heat Profile in furnace, foundries for Heat treatment application
• Primary & auxiliary temperature scanning of boiler
• Chemical & Hazardous area where data monitoring is essential
• Room Mapping in Pharmaceutical.
