Oilfield cenmenting tools downhole tools Float shoe&float collar
Descriptions:
Float collar and float shoe(guide shoe) are necessary conventional accessories for down-structure of casing string. float collat and float shoe is a heat-resisting, sealer and drillable tool. it's join easy and replace for guide shoe and casing shoe. it's used to protection casing and production casign, also used to deep well and ultra deep well. it classify ordinary type and self fill-up type according to way of drilling fluid get into.
Specification:
Size (in) |
Bore O.D(in) |
Bore ID(in) |
Min. Bore parameter(in) |
Thread type |
Ib(in2 |
|
|
Float collar |
5 1/2” |
6” |
4 3/4” |
2” |
5 1/2” LCSG |
4351 |
7” |
7 5/8” |
6 1/4” |
2 3/8” |
7”LCSG |
3626 |
|
9 5/8” |
10 5/8” |
8 5/8” |
2 3/8 |
9 5/8” LCSG |
3626 |
|
13 3/8” |
14 3/8” |
12 3/8” |
2 3/8 |
13 3/8” LCSG |
3626 |
|
|
Float shoe |
5 1/2” |
6” |
4 3/4” |
2” |
5 1/2” LCSG |
4351 |
7” |
7 5/8” |
6 1/4” |
2 3/8 |
7”LCSG |
3626 |
|
9 5/8” |
10 5/8” |
8 5/8” |
2 3/8 |
9 5/8” LCSG |
3626 |
|
13 3/8” |
14 3/8” |
12 3/8” |
2 3/8 |
13 3/8” LCSG |
3626 |
|
