Cheap Security Cctv Ptz Camera 700TVL With SONY Module R-800A6

Model:

R-800A6

module:

SONY FCB-EX480C

SONY FCB-EX480CP

Image Sensor:

1/3" Ex-view HAD CCD

Signal System:

NTSC

PAL

Effective Pixels:

38 thousands pixels

44 thousands pixels

Horizontal Resolution:

480 TVL

Lens:

18X optical zoom, f=4.1mm (WIDE)~ 73.8mm (TELE), F1.4 ~ F3.0

Digital Zoom:

12X    (216X zoom)

Horizontal Field:

48.0° (WIDE) ~ 2.8° (TELE)

Photograph Distance Range:

35mm (WIDE) ~ 800mm (TELE)

Synchronization mode:

Internal/External (V-Lock)

Minimum Illumination:

0.1Lux (color); 0.02Lux B&W

Signal to Noise Ratio:

>50dB

Electronic shutter:

1/1~1/10000 seconds, 22shifts

White Balance:

Auto / auto tracking / indoor / outdoor / one-touch mode / hand operation

AGC:

Auto / hand (-3~ 28dB level, 2dB / shift)

AEC:

Auto / manual / priority mode / illumination / EV compensation / Backlight Compensation

EVC:

-10.5 to +10.5dB (1.5dB/shift)

Back light Compensation:

ON / OFF

Privacy Protection:

On/Off (24 PCS)

Flash Restraint:

Auto

Display Screen:

Mode / Clock & Date / Caption Display

Focusing System:

Auto ( sensitivity: normal / lower ), one-touch auto focus, manual, alternate AF, Zoom trigger AF

Image Effect:

Electronic flip, reversion, black and white, mirror effect

Working Convert:

Long / Short Distance Zoom

Range of Video Output:

VBS:1.0Vp-p, Y / C output

Control Interface:

VISCA( TTL), WIDE: 9.6Kb/s,19.2Kb/s, 38.4Kb/s,

stop position:1/2 optional

Installation Temperature:

-20°C ~ 60°C

Working Temperature:

0°C ~ 50°C

Power Consumption:

24 AC/1.6W (motor unactivated), 3.3W (motor activated )

Weight:

About 8.1 oz (230g)

Size(W X H X D)

21/4 × 23/8 × 31/2 inch  (55.3×57.5×88.5mm)

Signal system:

NTSC / PAL

Mount method:

Wall mount / hoisting mount / in-ceiling mount

Synchronization mode:

Internal Synchronization

Application:

Indoor / outdoor

Shutter Speed:

1/50 (1/60) -------- 1/100,000 (second)

Signal to Noise Ratio:

48dB (AGC OFF)

Control Interface:

By wire, RS 485

Range of Video Output:

1.0Vp-p,75Ω (BNC)

Working Power:

DC 12V / 3A

Power Consumption:

3.6 W

Packing weight:

5.9 KGS ( include power adaptor, bracket and all parts )

Packing size:

In carton, 38cm (L) x 38cm (W) x 43cm (H)
