Help CenterMini NVR
US$ 29 - 31
MOQ: 1 Box
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Ratingsecu
Model Number:
R-M104B R-M108B
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
Ratingsecu
Model Number
R-M104B R-M108B
Features:
R-M104B:
Support 4CH 1080P / 960P / 720P, total 25M
* Playback channels: 4CH 960P / 720P or 1 CH 1080P
* Support 1 X 2.5 inch laptop hard disk (or USB mobile hard disk / E-SATA hard disk)
* Interface: HDMI X 1, VGA X 1, USB X 2, E-SATA X 1, 100M RJ45 X 1
* Without RS 485 interface. DC 5V / 2A power sypply.
* Size / weight: 160mm x 165mm x 35mm / 0.7 kg.
R-M108B:
Support 8CH 1080P / 960P / 720P, total 40M
* Playback channels: 4CH 960P / 720P or 1CH 1080P
* Support 1 X 2.5 inch laptop hard disk (or USB mobile hard disk / E-SATA hard disk)
* Interface: HDMI X 1, VGA X 1, USB X 2, E-SATA X 1, 100M RJ45 X 1
* Without RS 485 interface. DC 5V / 2A power sypply.
* Size / weight: 160mm x 165mm x 35mm / 0.7 kg.
| Main features of NVR: | ||||
| * Use HUAWEI Hisilicon chipset, professional for NVR, strong ans stable. | ||||
| * Support resolution of 1080P, 960P, 720P, VGA, etc. Support DUAL Streams. | ||||
| * ONVIF protocol 2.0 version. Compatible with most manufacturer's HD IP cameras. | ||||
| * Support 1 machine to show 2 screens (HDMI + VGA), 1 / 4 / 9 / 16 / 25 / 36 screen cust, can set automatical display by turns. | ||||
| * P2P remote surveillance, no need complicated settings to realize remote viewing, easily pass through different network. | ||||
| * One key to add IP cameras, simple operation, also can choose manually add IP cameras to the system. | ||||
| * 1 / 4 scrrens displayed by Main Stream, 9 or more screens displayed by Sub Stream, but when you double click the screen, it also change to show your main stream. | ||||
| * Mouse operate 15X digital enlarge image, can move the enlarged image to preview or playback. | ||||
| * Support play 4CH HD audio and video at the same time, 2 way voices intercom, with 3G / WIFI connection function. | ||||
| * Can move the tree menu, setting become more convenient. | ||||
| * Support enlarge the image of preview and playback. Support inquiry / playback / recording file according. | ||||
| * Ordering written of hard disk, start from 0 data, improve hard disk lifetime 2.5 times; | ||||
| * Can set users right and management. | ||||
| * Support remote view via computer, tablelet, smart phone. Support smart phone of IPHONE, ANDROID system. | ||||
| * With RS-485 connector, can NVR control keyboard to use the joystick to control HD IP PTZ / HD IP speed dome camera. | ||||
| * Multi-languages, support online upgrade. Free CMS. | ||||
