Specifications
ir ptz camera1. 1/3"Sony CCD , 700TVL
2. 8pcs Iimported array LEDs
3. IR distance is 100-120m
4. CE, FCC,ROHS,IP66
Outdoor IR PTZ camera CCTV security system speed dome ptz camera with night vision distance 120m
Features:
1.Private mold. 7" All aluminum alloy housing is waterproof for outdoor use.
External dial codes switch can set the Add Code and Baud Rate, needn't to open housing.
2.Designed and researched by us. Unique waterproof design for inlet wire, effectively avoid the water run into the housing in
storm and rainy weather, prevent the water run to machine if user use wrong install methods.
3.All IR LED with different illuminating angle, light is uniform, will auto turn on according to the lens zoom,
keep pace with the camera. IR LED have 2 levels and controlled by lens automatically.
4.Use silicone gasket, aluminum alloy housing and external waterproof fan, built-in semiconductor cooling device,
can auto control the temperature, excellent heat dissipation system ensure its stability.
5.10 PCS imported SMT IR LED, effective night vision distance is 100~120 meters.
6. High speed: Horizontal rotate 360°, 220°/sec, auto flip, vertical rotate 3°~90°, 100°/sec.
7.Function: 128 accurate preset positions, 2 pattern scan routes, 4 tour routes, 1 fixed monitoring position, display PTZ direction and zoom number, and temperature.
8.English OSD operation menu optional
Electricity
Working power: DC12V--(3A)
PTZ power: DC12V--/0.65A, IR light power: DC12V--(1A )
Lens power: DC12V/100mA, Camera power: DC12V/800mA
Environment
Working temperature:-35°C -- 69°C (temperature control): temperature inside dome below 45°C
Working humidity: 90%RH
Other information:
Working protocol: |
PELCO_D / PELCO_P |
Baud rate: |
2400bps / 4800bps / 9600bps / 19200bps |
Signal system: |
NTSC / PAL |
Mount method: |
Wall mount / hoisting mount |
Connection: |
RS 485 |
Application: |
Indoor / outdoor, day / night |
Certificate: |
CE, FCC, ROHS, IP 65, National patent |
Control Interface: |
By wire, RS 485 |
Range of Video Output: |
1.0Vp-p,75Ω (BNC) |
Working Power: |
DC12V / 750mA |
Power Consumption: |
3.6 W |
Packing weight: |
5.2 KGS ( include power adaptor, bracket and all parts ) |
Packing size: |
In carton, 32cm (L) x 32cm (W) x 43cm (H) |
Camera module information (in the dome housing)
Model: |
SV-9986 |
|
Image Sensor: |
1/3″sony ccd |
|
Effective Pixels: |
PAL:752(H)×582(V) ; NTSC:768(H)×494(V) |
|
Sensing Area: |
3.6mm × 2.4mm |
|
Signal System: |
PAL / NTSC |
|
Horizontal Resolution: |
700 TVL |
|
Built-in Lens: |
23X optical zoom, 3.3-99mm |
|
Minimum Illumination: |
0.05 Lux (IR ON) |
0.02 Lux (IR ON) |
Synchronization mode: |
Internal Synchronization |
|
Shutter Speed: |
1/50 (1/60) -- 1/100,000 (second) |
|
Signal to Noise Ratio: |
48db (AGC OFF) |
|
Day / Night Function: |
Sense IR light optical filter |
|
Focusing System: |
Auto Focus Fast |
|
IR night vision distance: |
100-120m |
|
power :
PACKING:
