automatic circular copy double cylinder socks weaving machine (3.5inch)

Specifications

automatic circular copy double cylinder socks knitting machine featuring good mechanical performance, high stability.
WH-6F-A

Modle	Needle Cylinder	Main Product	No.of needles and needle selections	Technical specification
WH-6F-A1	3 1/2inch plain sock machine	Cotton socks	56-220N 6 Needle selection	Maximum speed plain:320RPM 13 adding yarn shutttle eight pneumatic shuttles in yarn line.automatic yarn in
WH-6F-A2		Naked spandex socks	56-220N 6 Needle selection
WH-6F-A3		Copy double cylinder rsingle rib socks	56-200N 6 Needle selection
WH-6F-A4		Looping five-toes socks	56-168N 6 Needle selection
WH-6F-A5		A moulding boat socks Three-dimensional socks	168-200N 6 Needle selection

 Funtion introduction
1.one feeder into yarn
2.Elestic shuttle(can buy two) knit different colors
3.Six colors in one line,there are 13 colors in the socks pattern
4.High heel,big heel,small heel,180 degree against sock mouth,two colors for sock heels,soks toes,can knit 3D socks
5.Taking the double shovel-needle technology,when knitting the heel and toe,the angle is adjusted by computer In this way,can improve the efficiency,overcome the shortcoming of sigle Shovel—needIe
6.The maximum horizontal stroke pulls is 39cm
