HCVAC NEW high complex equipment for film coating/metallized film machine/silver coating plastic items :
| DETAILED DESCRIPTION |
The equipment adopts the resistance heating in the vacuum chamber, to melt and vaporize the metal wire (aluminum wire) cling to the resistance wire. The vaporized metal molecule deposit on the substrates, to gain the smooth film as well as high reflectivity. Thus the surface of the items can be decorated and beautified.
Thermal Resistance Evaporation Coating Technology: Thermal vacuum deposition is one method for fabricating thin films under a high vacuum environment also addressed as "thermal evaporation method". With this method, an electron beam (e-beam) or resistive heating is usually used to evaporate the desired material inside the vacuum coating chamber, which then adheres to a substrate placed above it. This method can classified as a form of PVD, which stands for physical vapor deposition, and is suitable for fabricating high-quality thin films with thicknesses on the order of nanometers on glass, plastic, films, metals, and almost any other kind of material.
Features
Characteristic: reasonable structure, even film, good-quality film forming, quick pumping speed, the cycle of short, high efficiency and easy operation, low energy consumption and performance advantages of stability.
Machine Features:
-High reliability
-High productivity and flexibility
-Consistently brilliant end product quality
-Full automation capability
-Excellent coating flexibility
-Long lifetime and fast target exchange
-Flexible system configuration
-High speed coating and best PVD homogeneit
| Application | |
Applied industry: Widely used in automotive, audio and varinous small appliances, computers, clocks and watches, toys cell phones reflective Cup, cosmetics toys tableware sanitary shoe heel, ABS, PS, PP, PC, PVC, PET, nylon,metal, Boli, glass, ceramics, TPU, etc.
Electroplating effects: general electroplating-face, dumb-(semi-mute, all dumb), the electroplating process wrinkles, wiredrawing,raindrop ect.
Coating color: gold, silver, red, blue, green, purple,rainbow color ect.
| TECHNICAL DATA |
| Mode | ZZ-1214 | ZZ-1416 | ZZ-1618 | ZZ-1820 |
| Dimension (D*H) | 1200*1400mm | 1400*1600mm | 1600*1800mm | 1800*2000mm |
| Film type | Semitransparent film, non-conducting film, gold, silver, red, blue, green, purple, seven color, etc | |||
| Power source | Thermal evaporation power, ion bombard power, RF power | |||
| Vacuum chamber structure | Vertical double/single door, horizontal single door, pump system postposition | |||
| Ultimate vacuum | 8.0*10-4Pa | |||
| Vacuum system | Diffusion pump +Roots pump +Mechanical pump +Holding pump | |||
| Pump time | Pump from atmosphere to 5.0*10-2,<=6 minutes | |||
| Workpiece motion mode | Public rotation/ Frequency control | |||
| Control mode | Manual/Automatic all in one mode, Touch screen + PLC | |||
| Remark | We can design the dimension of the equipment according to customer’s special technique requirement. | |||
| MACHINE PHOTOS |
| SAMPLE PHOTOS | |
| ABOUT HUICHENG |
Dongguan Huicheng Vacuum Technology Co., Ltd. is a high-tech enterprise specialized in the R& D,
production, and marketing kinds of Vacuum coating machine and related products. We start in this field in1997,and already install machines more than 65 countries.HCVAC can help you to enter the PVD coating easily by our vacuum coating machine and full range service. We will provide with most suitable technology according to your requirements.
We will make the special coating solution for each customer; combine the full set production technics to meet your requirements, to ensure high efficiency of production.
Easy to implement
To many people unfamiliar with the process, PVD coating technology seems complicated. However, with the right investments and a good support, it is easier than expected. HCVAC has developed a turnkey coating process that makes a PVD coating centre easy to implement. A complete coating process consists of several steps: stripping (depending on the part’s history); pre-treatment; quality control; cleaning & drying; fixturing & visual inspection; PVD coating; quality control & thickness measurement and post-treatment (depending on the application). These steps are all available from one partner: HCVAC Technology, including mature technics and coatings.
| HUICHENG HONOR |
| PHOTO WITH CLIENTS & SUCCESSFUL CASE |
We developed a complete after-sales system and effective service measures. Company now
owns a professional after-sales service team with more than ten experienced engineers.
ISO 9001 standard to ensure the quality can meet the customer’s requirements.
Please feel free to contact us for further information!
Contact person: Sophia Guo
Mobile/what'sapp/wechat: +86-13600282018
Skype: sophia8716
Email: sophia(at)
QQ:1611745811
