Economic Flat Tunnel uv Curing Unit for After uv Ink Printing
US$ 500 - 2,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other, Curing
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Flat & Round Tunnel Tabletop Style UV Curing Machine UV Curing System Full Rotary LetterpressUS$ 13,000 - 15,500MOQ: 1 Set -
Seat-stand Style High Quality UV Coating Machine for Mobile Phone CaseUS$ 1,780 - 2,750MOQ: 1 Set
-
Tunnel Style Flat & Round High Quality UV Curing Machine UV Curing MachineUS$ 13,000 - 15,500MOQ: 1 Set
-
Factory Supply Tunnel High Quality Flat & Round UV Curing MachineUS$ 13,000 - 15,500MOQ: 1 Set
-
High Quality Flat & Round Professional UV Curing Machine Crystal Photo Drying MachineUS$ 1,780 - 2,750MOQ: 1 Set
Condition
New
Plate Type
Other, Curing
Place of Origin
Guangdong, China
Brand Name
Hengxin
Model Number
HC-UV300
Usage
Other, dry UV ink
Automatic Grade
Semi-Automatic
Voltage
110/220V
Gross Power
4000W
Dimensions(L*W*H)
130*65*113cm
Weight
102KG
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
simple mini portable UV exposure machine unit
Technique data:
- Power: 220V
- UV tube equipped: 2000W * 2pcs
- Conveyor belt width: 300mm
- Transport speed: 5 ~ 25 M / min
- Height of feeding throat: 30mm
- Machine frame length: 1.2M
- Outer dimension: 130*65*113cm
- Packing size: 135*70*130cm
- N.W. / G.W.: 102kg / 152kg
Application range:
UV drying machine is used for drying screen printing ink by UV ultraviolet (UV) light curing. It can be used in UV light oil, grinding, wrinkles, snowflake, foaming, crystal convex oil, marble, refractive index, various UV color, etc.
Configurations:
- China domestic / import UV light is available, high gather reflective chimney
- PVC Teflon conveyor belt
- Stepless motor import from Taiwan
- Manda brand cooling fan with high quality
Main performance:
- 2 sets of UV light source system configuration, according to the number of open lamp production needs.
- PVC heat-resistant Teflon conveyor belt, Seiko produced, smooth operation noise
- UV light height of chimney can be adjusted
Applicable range
Used for drying screen printing ink of UV ultraviolet (UV) light curing. Can be used in UV light oil, grinding, wrinkles, snowflake, foaming, crystal convex oil, marble, refractive index, various UV color, etc.
Main performance
- 2 sets of UV light source system configuration, according to the number of open lamp production needs.
- Import Teflon conveyor belt, Seiko produced, smooth operation noise
- The belt speed motor and speed stainless speed conveyor speed visual production situation
- Convergent design, high light-gathering reflective chimney, instant drying speed, when the express.
- UV light height of chimney can be adjusted
- UV lamp working current can be shown by the master, UV analogue display system working condition
- Equipped with exquisite cooling system, prevent the working chamber at high temperature, the effective protection of production work environment.
Configuration
1. UV light, high gather reflective chimney
2. Teflon or stainless steel mesh belt
3. Stepless motor import from Taiwan
4. Manda brand cooling fan with high quality to ensure safety
