Grinding Machine for Abrasive Powder
General
Grinding Machine for Abrasive Powder adopts the most suitable flow field calculated by our Hydromechanics Numerical Similitude Software, which makes a breakthrough in particle acceleration technology and a great improvement of grinding efficiency, saving energy and avoiding over-ground fineness. The ground products are in accordance with the international standard and the Optical standard (e.g.: W63-W5, Japanese Standard JIS240#-3000#, and European Standard F230/53-F1200/3).
Features
- Particle-to-particle attrition, reduced wear and no iron contamination, without acid cleaning.
- One-time grinding and classifying can process any grade products, with narrow particle size distribution and no oversized particles;
- Obtain production with ideal particle size distribution, free of water separating and washing.
- Two particle size sections simultaneously; (It can be used as a grinder and classifier or a classifier alone)
- Make full use of jet energy and grinding force control technology.
- Integrated, stable and uniform flow field control technology.
- No leakage of coarse particles.
- Long and stable operation.
- Long service life.
- Particle’s shape control technology.
- Control the ratio of products in any grade.
- Operation is conducted under fully sealed negative pressure, without dust pollution.
Model |
Air/Gas Consumption (m3/min) |
Max. Feeding Size (mm) |
Product Size |
Grade(s) |
Capacity (Kg/h) |
Power (Kw) |
LNJ-36A-2 |
6 |
<3 |
W63-W3.5 |
1 |
10-100 |
<51 |
LNJ-36A-3 |
6 |
<3 |
W63-W3.5 |
2 |
10-100 |
<51 |
LNJ-120A-2 |
20 |
<3 |
W63-W3.5 |
1 |
50-450 |
<143 |
LNJ-120A-3 |
20 |
<3 |
W63-W3.5 |
2 |
5-450 |
<160 |
LNJ-120A-4 |
20 |
<3 |
W63-W3.5 |
3 |
50-450 |
<180 |
Note: the above parameters are for classifying jet mill; it can be used as classifier alone (without air compressor). | ||||||
Diamond, green (black) silicon carbide, brown (white) Corundum, Cubic Boron Nitride, Garnet, Zircon sand, Quartz sand, Tungsten Carbide, Ceramics, refractory etc.
Office and Plant
Patents
Communication with customers
