Low Resistivity Cuni Alloy Wires CuNi14

Name: Low Resistivity Cuni Alloy Wires CuNi14
Brand: Jinyang
SKU: 129893785

Negotiable MOQ: 50 Kilograms (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Liaoning, China

Type:

Nickel Wire

Application:

Heating elements

Shenyang Tianzhong Alloy Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian port or other Chinese ports

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Liaoning, China

Type Nickel Wire

Application Heating elements

Grade Nickel copper

Ni (Min) 14%

Powder Or Not Not Powder

Model Number CuNi14

Brand Name Jinyang

Specifications

Product name:Low resistivity cuni alloy wires CuNi14
Other names:Low resistivity cuni alloy wires;cu-ni alloy wire

Product info

Product name: Low resistivity cuni alloy wires CuNi14

Otrher names: Low resistivity cuni alloy wires;cu-ni alloy wire

Application Range

This type of alloy wires is usually as key components assembled into the core of thermal over load relay,

low resistance thermal circuit breaker and other low resistance electronics.

Product features

The description of products

should be followed the JB/T6454-2008 standard.

Number	ResistivityuΩ·m(20°C)	maximum service temperature(°C)	resistance- temperature coefficient 10⁵/°C (20-600°C)	copper thermoelectric emfs V/K(0-100°C)	chemical composition,%				Mechanical Properties(soft)
					chemical composition,%				Tensile strength N/mm²(no less than)	elongation, %(no less than)
					Mn	Ni		Cu	Tensile strength N/mm²(no less than)	diameter≤1.00mm	diameter>1.00mm
NC003	0.03	200	< 120	- 8			1	remain	210	18	25
NC005	0.05	200	< 100	-12			2	remain	220	18	25
NC010	0.10	220	< 60	-18			6	remain	250	18	25
NC012	0.12	250	< 57	-22			8	remain	270	18	25
MC012	0.12	200	< 38	-	3		-	remain	290	20	25
NC015	0.15	250	< 50	-25			10	remain	290	20	25
NC020	0.20	300	< 38	-28	0.3		14.2	remain	310	20	25
NC025	0.25	300	< 25	-32	0.5		19	remain	340	20	25
NC030	0.30	300	< 16	-34	0.5		23	remain	350	20	25
NC035	0.35	350	< 10	-37	1.0		30	remain	400	20	25
NC040	0.40	350	0	-39	1.0		34	remain	400	20	25
NC050	0.49	400	< -6	-43	1.0		44	remain	420	20
