Product Name
Product name:copper clad aluminum wire
Product Application: 0.18mm enameled copper clad aluminum wire for transformer or motor winding
Product Specification
Product spec |
Copper layer (volume ratio%) |
Copper layer (quality ratio%) |
Density (g/cm3) |
DC Resistivity (Ωmm2/m) |
DC Conductivity (%IACS) |
CCA-10% |
8-13 |
27 |
3.32 |
0.02743 |
63 |
CCA-15% |
13-17 |
37 |
3.63 |
0.02676 |
65 |
Pure copper wire |
100 |
100 |
8.89 |
0.01724 |
100 |
1. Temperature Class: 130, 155, 180 centigrade
2. Performance feature: High mechanical strength, soft-resistance and high temperature for breakdown, high performance for shaving-resistance and solvent-resistance;
3. Main applications:Can be used as the winding wire of all kinds of electric motors, electric appliances, meters and telecommunication apparatus.
4. Specification: Diameter 0.04mm~1.60mm (thin paint film, thick paint film, paint film requested by clients
The physical characteristic of Tinned pure copper wire:
Specification(mm) |
Copper layer(volume ratio%) |
Extensibility(%) |
DC Resistivity(Ωmm2/m) |
Density(g/cm3) |
0.05-0.06 |
≥99.98 |
≥6 |
≤0.017241 |
8.89 |
0.07-0.09 |
≥99.98 |
≥10 |
≤0.017241 |
8.89 |
