Help CenterFlat Steel Bar
US$ 300 - 400
MOQ: 25 Metric Tons
Key Specifications
Get Latest Price
Standard:
AISI, ASTM, BS, DIN, GB, JIS
Thickness:
3-20MM
Width:
25MM-800MM
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Standard
AISI, ASTM, BS, DIN, GB, JIS
Thickness
3-20MM
Width
25MM-800MM
Place of Origin
Tianjin, China
Technique
Hot Rolled
Special Use
Mold Steel
Name |
Flat steel bar |
Specification |
as your requirement |
Thickness |
|
Width |
25mm~800mm |
Length |
50-12000mm as your requirements |
Tolerance |
as Chinese standard |
Grade |
A36, SS400,S235,S275,S275JR,Q235B |
Standards |
ASTM,EN,DIN,GB,JIS |
Surface Treatment |
Vanished,painted,oiled,galvanized |
Packaging |
Standard exporting packing or as client's requirement |
Certificate |
BV,ISO9001:2008 and Mill test Certificate |
|
The above are the general items, for the special types, we can also meet your needs. | |
The flow chart:
| General specifications | |||
| Flat Bar | |||
| Width | Thickness | Length | Theoretical Weight |
| (mm) | (mm) | (m) | (kg/m) |
| 20 | 2 | 6/9/12 | 0.31 |
| 20 | 2.5 | 6/9/12 | 0.39 |
| 20 | 2.75 | 6/9/12 | 0.43 |
| 25 | 2.5 | 6/9/12 | 0.49 |
| 25 | 3.75 | 6/9/12 | 0.74 |
| 30 | 2.5 | 6/9/12 | 0.59 |
| 30 | 3.5 | 6/9/12 | 0.82 |
| 30 | 9.75 | 6/9/12 | 2.3 |
| 40 | 3.5 | 6/9/12 | 1.1 |
| 40 | 4.75 | 6/9/12 | 1.5 |
| 40 | 11.75 | 6/9/12 | 3.69 |
| 50 | 2.75 | 6/9/12 | 1.08 |
| 50 | 4.5 | 6/9/12 | 1.77 |
| 50 | 9.75 | 6/9/12 | 3.83 |
| 60 | 5.5 | 6/9/12 | 2.6 |
| 60 | 7.5 | 6/9/12 | 3.53 |
| 60 | 11.5 | 6/9/12 | 5.42 |
| 80 | 5.5 | 6/9/12 | 3.45 |
| 80 | 7.5 | 6/9/12 | 4.71 |
| 80 | 11.75 | 6/9/12 | 7.38 |
| 100 | 3.25 | 6/9/12 | 2.55 |
| 100 | 4.75 | 6/9/12 | 3.73 |
| 100 | 7.5 | 6/9/12 | 5.89 |
| 120 | 9.75 | 6/9/12 | 9.18 |
| 120 | 11.75 | 6/9/12 | 11.07 |
| 150 | 9.75 | 6/9/12 | 11.48 |
| 150 | 11.5 | 6/9/12 | 13.54 |
| 150 | 13.5 | 6/9/12 | 15.9 |
| 160 | 11.75 | 6/9/12 | 14.76 |
| 200 | 9.5 | 6/9/12 | 14.92 |
| 250 | 5.75 | 6/9/12 | 11.28 |
| 340 | 7.75 | 6/9/12 | 20.68 |
