Specifications
gemstone mining tools1.reasonable price
2.high speed cutting with efficiency
3.high abrasive resistance.
gemstone mining tools
duct details
Item | Description | |||||
Type | Diameter | Height | Diamond thickness | Diamond chamfer | Carbide Substrate chamfer | |
0808 | 8.2mm | 8mm | 1-2.5mm | 0.2mmX45° | 0.5mmX45° | |
0811 | 8.2mm | 11mm | 1-2.5mm | 0.2mmX45° | 0.5mmX45° | |
1008 | 10mm | 8mm | 1-2.5mm | 0.2mmX45° | 0.5mmX45° | |
1304 | 13.3mm | 4.5mm | 1-2.5mm | 0.2mmX45° | 0.5mmX45° | |
1305 | 13.3mm | 5mm | 1-2.5mm | 0.2mmX45° | 0.5mmX45° | |
1308 | 13.44mm | 8mm | 1-2.5mm | 0.2mmX45° | 0.5mmX45° | |
1313 | 13.44mm | 13.2mm | 1-2.5mm | 0.2mmX45° | 0.5mmX45° | |
1608 | 16mm | 8mm | 1-2.5mm | 0.2mmX45° | 0.5mmX45° | |
1613 | 16mm | 13.2mm | 1-2.5mm | 0.2mmX45° | 0.5mmX45° | |
1908 | 19.05mm | 8mm | 1-2.5mm | 0.2mmX45° | 0.5mmX45° | |
1913 | 19.05mm | 13.2mm | 1-2.5mm | 0.2mmX45° | 0.5mmX45° | |
1925 | 19.05mm | 25mm | 1-2.5mm | 0.2mmX45° | 0.5mmX45° | |
We can make any sizes as your requirement | ||||||
Material | 100% Cemented carbide substrate and Diamond layer | |||||
Application | PDC (polycrystalline Diamond Compact) drill bit is a new product after the hot-pressed and electroplated drill bit in recent years. With special high-frequency welding techniques, PDC of high wear resistant is welded to the body as cutting edges. PDC bit is mainly used for geological prospecting coal exploration, water conservancy and power engineering, etc.And mechanical industry,oil well drilling,coal mining or quarrying. | |||||
Characters | PCD bits uses PCD as main cutting components, with the excellent wear-resisting and impact toughness of the PCD.It has a long useful life, high-efficiency, and good cost performance. | |||||
Productive technology | Surface treatment | Sinter | ||||
“Mirror” polishing | High temperature high pressure sintering | |||||
Abrasive ratio | >185 | |||||
| OEM /ODM | Sample | ||||
Yes | available | |||||
duct photos
III.Product application
IV.Company introduction
Chengdu best new materials Co., Ltd. located in Chengdu, China. We are a professional manufacturer
& exporter of 1. metal powders ; 2.cemented carbide tools etc.
Our well-equipped facilities and excellent quality control throughout all stages of production enable us
gained a global sales network reaching Japan, South Korea, Poland, Iran , Syria, England, the United States,
Turkey and Brazil etc.
V.certificate
VI.Why Choose us
1.100% factory manufacture and factory direct sales
2.Competitive price and quality guaranteed
3.Small order also welcomed.
4.Sample free is available .
5.Delivery on time.
6.We have more than 10 years experience.
7.We have through the ISO9001 quality management system certification.
8.We have a professional team and technical personnel.
VII.packing and delivery
Our prduct delivery by EMS/DHL /TNT/FedEx /PUS and so on .
VIII.Why choose Carbide Inserts
1.Higher speeds and feeds allowed.High temperature resistance.
2.The carbide insert provides exceptional wear resistance at the cutting edge.
3.Last longer due to carbide insert forming surface resisting wear.
4.Carbide Insert are high hardness and good abrasion resistance.
FAQ
Q:What is cemented carbide ?
A: Cemented carbide is a hard material used in machining tough materials such as carbon steel or stainless.
Carbide tools can also withstand higher temperatures .
Q: Which grades are useful in metal forming applications?
A: Grades employed for metal forming applications are typically based on coarse grain sizes (3 to 8 mm) and
high binder contents (15 to 30 wt. %).
Q: Which grades are useful in earth drilling or boring applications?
A: The best compromise is usually arrived at by using grades that are based on coarse grain sizes (3 to 8 mm)
and relatively low Co levels (6 to 16 wt. %).
