Waterproof Reinforced XPS Shower Base

Waterproof Reinforced XPS Shower Base photo-1
Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Olingen
Model Number:
OBB-3
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI/NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Zhejiang, China
Brand Name Olingen
Model Number OBB-3


Waterproof reinforced XPS shower base



Product Overviews

Olingen shower tray, also known as waterproof shower base, shower pan, shower lay, waterproof wetroom floor insulation board.

Olingen XPS shower base is a low-cost, easy-to-install waterproof base, used in the design of a wet room for the home and suitable to be fixed to both timber and concrete floor. The tray is easily cut into any size or shape and forms a floor level, barrier- free panel ready to receive tiles with a preformed slope to the drain.




Product structure:

Made of high-performance waterproof extruded polystyrene, it has a 0.75mm coating on either side comprising a glassfiber mesh embedded in a polymer cement mortar.

Waterproof reinforced XPS shower base

Waterproof reinforced XPS shower base





SIze available :



Shower base







800*800

central drain

1000*1000

offset drain

900*900

central drain

1000*1200

offset drain

1000*1000

central drain

800*1800

offset drain

1200*1200

central drain

1200*900

offset drain

1500*1500

central drain

800*1500

offset drain

1200*900

central drain

800*1200

offset drain

1200*800

central drain

1200*1200

offset drain



  We accept customized shape, size, drain position .



Product Display

 Waterproof reinforced XPS shower base



Product Advantage

 Waterproof reinforced XPS shower base



Project Cases

 Waterproof reinforced XPS shower base

 Waterproof reinforced XPS shower base



FAQ



Why do I need Olingen BOARD?
Because Olingen BOARD will save you money by acting as a very efficient insulation barrier. It reflects the heat upwards into the floor tile instead of allowing the heat to warm up the concrete slab below. Besedes, it  not only  has the function of heat insulation and strong waterproofness, but also provides a base for the ceramic tile.
How does  compare to plasterboard?
It doesn’t there really is no comparison. Standard plasterboard offers approximately 1/6th the U value of an equal thickness of Olingen BOARD. and yet is approximately 7 times heavier. When used in wet areas, such as bathrooms or showers,Olingen BOARD is totally waterproof whereas plasterboard will absorb water unless it is of the waterproof variety which will cost considerably more.
Compare a few characteristics of Olingen BOARD against plasterboard
1. 1/7th the weight of Plasterboard
2.waterproof, ordinary plasterboard is not.
3.(10mm) has a U value of 2.7 against 12.8 W/M2 K of 12.5mm

What thickness  Olingen BOARD do I need?
The thicker the Olingen BOARD the better the heat insulation, but obviously if you have an existing floor that you want to insulate, you may well be governed by the thickness you can add to the floor because of the height from the finished floor to the underside of your door. Even by using 6mm Olingen BOARD you will notice the benefit of insulating with Olingen BOARD .Generally speaking,,6mm and 12mm are used for floor while thicker than 20mm are usually for wall partition.

How do I fix Olingen BOARD to walls?
The board can be either fixed to timber battens with screws and screw cups or fixed directly to brick or block walls by drilling, plugging and screwing the boards to the wall. If the wall is to be plaster finished, the joints should be reinforced with a plaster scrim

How to store Olingen BOARD ?
To ensure the boards flat ,the boards should keep level. Boards can't exposed to fire or other organic solvent so that board can be provented from ultraviolet radiation during long-term storage. Slight bowing caused by incorrect storage or transport, for example, is not permanent and does not represent a technical defect. Slight curving can be rectified through storing the boards flat.



Company Information

  Olingen Group is a professional supplier in architectural material for 20 years, owned 5 factories, 7 subsidiaries and 8 individual brands. Main products include: cultured stone,cultured brick,Sands stone,imitation wooden products,EPS components,brick panel,wall insulation,tile backer board,xps shower tray and other building materials.
