GQ50 Electric Electric Steel Bar Bending Machine 50 Steel Cutting Machine

 The Product Description for the  GQ50 electric electric steel bar bending machine 50 steel cutting machine

1. Reinforced enclosure, compact structure, movable wheels

2. Good lubricating properties. Adopt closed structure, use Gear Splash to lubricate, fill in 8-12kgs oil, the machine could work continuously for more than 3 month

3. Low power loss. The gear uses rolling bearing, low frication, could save 1/3 power comparing with other rebar cutting machines

4. Quality core advantage

l)High hardness blade base and connection rod. Using high speed standard motor, high quality and steady performance, longer service life

l)All the gear shafts are produced by our own CNC processing center, high accuracy of size and excellent quality

l)All gears are extra thick and heavy, the whole machine is extra thickl

l)Crank shaft is made by Cr40, high hardness and corrosion resistance, can work in heavy duty

1. The operation disc material carbon structure steel 45# size Φ400mm*45mm and Φ380mm*45mm.

2. The painting , beautiful anti-rust spray painting inside and outside .

3. The stop gauge can be installed from four different corners to realize the requirement of putting steel bar from various directions.

 4. It is fully enclosed gear-box, low noise, high and low speed, which is easy for the worker to operate.

 5. It adds eccentric bushing, ultrahigh hardness accessories and adjustable baffles, so it will have longer service life.

As the transmission figure shows: Motor 1 via V-belt drive the large pulley 2 to make it turn, the even shaft gear 3 mesh the gear 4, II axis even shaft gear 9 mesh the III axis gear 10, III axis even shaft gear 5 mesh the swimming gear 6, the torque transmitted to crankshaft drive the connecting rod 12 to push movable knife seat 13 to cut.

 The Packaging and Shipping for the 40 type Steel bar cutting machine stainless steel cutting machine

steel tube cutting machine
Follow the clents' requests.

 The Application for the 40 type Steel bar cutting machine stainless steel cutting machine is easy used in some place: mainly used for cutting carbon steel, cold and hot round steel,screw head steel, deformed steel, flat steel , angle steel and square steel in construction project. It can be class fied GQ40,GQ50,GQ60,GQ70 model bar cutting machine according to max working capacity 40mm, 50mm, 60mm and 70mm.

  SHIFENG enterprise group as early as 2004, as an executive director of the China Hardware Association, our company was the first to pass the 2000 version of ISO9001 quality certification system in the hardware industry.

For our company we also can provide some other popular tools for example the Drill (Hammer drill, Electric drill, Cordless Drill, Impact drill),  Drinder( Die grinder, Bench grinder, Angel grinder), Saw ( Cirular saw, Chain saw, Miter saw, Jig saw , Plastic welding machine)  Orbital sander, Cut off machine, Electric planer , Car polisher, Electric blower , Electric router, Electric hammer.  You can also click this, to see our company product.

SHIFENG is a private enterprise group, which has a diversified development in hardware manufacturing chain sales, marketing management, and real estate investment and development.

  As early as 2004, as an executive director of the China Hardware Association, our company was the first to pass the 2000 version of ISO9001 quality certification system in the hardware industry.  SHIFENG is a company specialized in eletromechanical tool products.We supply all kinds of products with high qualities and reasonable prices.And we also have a professional sales and after sales service team. Mainly sell all kinds of electric tools, pneumatic tools, machine tools, welding & cutting machine, drilling equipment and related spare parts, accessories, etc. We adhere to the prosperity of the hardware industry and the market economy as our duty and uphold the "spring service, Great Wall quality" business philosophy, which give us a great reputation all over the world. We are promising to be the best brand in china architectural hardware circulation!

Picture 1: Our company  large-scale logistics distribution centers  :    We have four large-scale logistics distribution centers, three processing factories.

Picture 2: Our company shops:  Our company Has a chain of 55 sales outlets in the country .

Picture 3: our company culture:

With more than 100 management staffs , and 1000 employees, we have already ranked first in the hardware industry sales!

SHIFENG is adhering to the corporate culture of “Lower price, better quality”, creating higher value for shareholders, customers and society. We are promising to be the best brand in china architectural hardware circulation!

1. Technical guidance (24 hours online tradmanager, skype, mobile).

2. Loading inform (loading port, destination port, shipping date, weight etc.)

3. Within warranty period, we will provide free parts for replacement if any problem belongs to us.(delivery cost paid by customer). After the warranty period the parts are offered at cost price

4. If you need the on-site show, welcome to our factory.

5. 20 years export experience
6.Bad loss rate
7.Price is competitive
8.ISO9001:2008
9.No Resellr,directly manufacture
10.Good after-sell service
