Ducile Iron Pipe

Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Type:

Drill Bit

Machine Type:

Other, Iron Pipe

Material:

High Manganese Steel

Shaanxi APS Machinery Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin Port China

Delivery Detail:

Delivery time depends on order quantity.

Type Drill Bit

Machine Type Other, Iron Pipe

Material High Manganese Steel

Processing Type Forging

Use Other

Product Description

DN(mm)	DE(mm)	W.T.(mm)			Socket convex portion Approximate weight (kg)	kg/M			Total Weight (kg) (standard working Length 6000mm)			Total Weight(kg) (Standard Working Length 5000mm)
		K8	K9	K10		K8	K9	K10	K8	K9	K10	K8	K9	K10
80	98	6	6	6	3.4	12.2	12.2	12.2	76.5	77	77	64.4	64.4	64.4
100	118	6	6.1	6.1	4.3	14.9	15.1	15.1	93.7	95	95	78.8	79.8	79.8
125	144	6	6	6.3	5.7	18.3	18.3	19	119	119	121	97.2	97.2	100.7
150	170	6	6.3	6.3	7.1	21.8	22.8	22.8	138	144	144	116.1	121.1	121.1
200	222	6	6.4	6.4	10.3	28.7	30.6	30.6	183	194	194	153.8	163.3	163.3
250	274	6	6.8	7.5	14.2	35.6	40.2	44.3	228	255	280	192.2	215.2	235.7
300	326	6.4	7.2	8	18.9	45.3	50.8	56.3	290	323	357	245.4	272.9	300.4
350	378	6.8	7.7	8.5	23.7	55.9	63.2	69.6	359	403	441	303.2	339.7	371.7
400	429	7.2	8.1	9	29.5	67.3	75.5	83.7	433	482	532	366	407	448
450	480	7.6	8.6	9.5	38.3	80	89	99	515	574	632	438.3	483.3	533.3
500	532	8	9	10	42.8	92.8	104.3	115.6	600	669	736	506.8	564.3	620.8
600	635	8.8	9.9	11	59.3	122	137.3	152	791	882	971	669.3	745.8	819.3
700	738	9.6	10.8	12	79.1	155	173.9	193	1009	1123	1237	854.1	948.6	1044.1
800	842	10.4	11.7	13	102.6	192	215.2	239	1255	1394	1537	1062.6	1178.6	1297.6
900	945	11.2	12.6	14	129	232	260.2	289	1521	1690	1863	1289	1430	1574
1000	1048	12	13.5	15	161.3	275	309.3	343.2	1811	2017	2221	1536.3	1707.8	1877.3
1200	1265	13.6	15.3	17	237.7	374	420.1	466.1	2482	2758	3034	2107.7	2338.2	2568.2
