API 11B Sucker Rod Coupling Class T and SM/Anti-wear Coupling/Polished rod coupling/Slim hole coupling
-Couplings:
Standard: API Spec 11B
Size: 5/8", 3/4", 7/8", 1", 1-1/8"
Length: 4", 4.5"
Grade: T & SM
1. Class T and Class SM coupling for sucker rods are manufactured as per API 11B.
2. Class T coupling is using AISI 5140 to manufacture.
3. As for Class SM coupling, the spray metal is a specified hardening process which is used on the base metal The couplings are available in full size, slim hole and over size.
4. Combination couplings are available for different diameters (sub-coupling) for both Class T and Class SM couplings.Sucker rod coupling is one of our flagship products.
5. One sucker rod coupling must be processed by a few fabrication procedures, such as, Blanking, drilling hole, boring hole, milling, thread tapping etc.
Name |
Size |
Grade |
Characters |
Sucker rod coupling |
5/8”, 3/4”, 7/8”,1”, 1-1/8” |
T, SM |
Couplings and slim hole couplings |
Sub coupling |
5/8”-3/4”, 3/4”-7/8”, 7/8”-1”, 1”-1-1/8” |
T, SM |
Connecting two sizes of sucker rod or connecting sucker rods and polished rods |
Polished rod coupling |
5/8”, 3/4”, 7/8”,1”, 1-1/8” |
T, SM |
9º degree cone |
Slim hole coupling |
5/8”, 3/4”,7/8”, 1” |
T, SM |
Slim hole sucker rod couplings, polished rod couplings and sub-couplings |
