API SPEC. 7-1 Downhole Integral Spiral Steel Drill Collar, Non-magnetic Drill Collar in Oil Field with High Quality
- 10000 Piece / Pieces per Month
- Tianjin Port
- T/T Credit Card PayPal
You May Like
-
Seamless Casing Pipe, Steel Grade J55,N80,P110,PH-6, Oil and Gas Casing and Tubing as API 5CT
-
API Downhole Non-magnetic Drill Collar, Integral Spiral Steel Drill Collar in Oil and Gas
-
API 5CT Spec. Oil Seamless Casing Pipe, Steel Pipe Casing and Tubing in oil and gas
-
API SPEC. Seamless Tubing Pipe, Oilfield OCTG Casing,Tubing Steel Pipe in Oil and Gas Drilling Tools
-
API 5DP Oil and Gas drill pipe steel grade G105, S135, Petroleum Drill Pipe Trade Assurance
-
API 5DP drill pipe steel grade G105, S135 in oil and gas, Petroleum Drill Pipe
Product Details
| Brand Name | APS | Model Number | Integral spiral drill collar | |
| Type | Drill Collar | Machine Type | Drilling Tool | |
| Certification | API | Material | Other, Alloy steel, Non-magnetic | |
| Processing Type | Forging | Use | Well Drilling |
Product Description
API SPEC. 7-1 Downhole Integral Spiral Steel Drill Collar, Non-magnetic Drill Collar in Oil Field with High Quality
Drill collar is basic component which provides weight on the bit for drilling and keeps the drill sting in tension. Drill collar is manufactured from 4145H modified quenched and tempered steel, strict metallurgical specifications are followed to insure that full length heat treating produces a consistent maximum depth of hardness.
* Slick Drill Collar: provide weight to drill bit so that drill pipe is in tension. Especially the drill collar can keep centralizing for drill bit and hole track by large rigidity.
* Spiral Drill Collar: reduce contact area with hole so as to avoid efficiently bit sticking from diffirential pressure.
* Non-magnetic Drill Collar: as cold rolled finish on both ID and OD surface with unique technical process strengthen the structure and ensures the tools with optimal resistance to stress, corrosion, cracking and the mechanical performance is greatly enhanced.
1. Material AISI 4145H, 4145HMod, Non-Magnetic Drill Collar
OD+4mm | Connection | ID+1.59mm | Length±152.4mm | Chamfering Diameter ±0.4mm | Length of one spiral ±25.4mm |
79.4 | NC23 | 31.8 | 9140 or 9450 | 76.2 | 679 |
88.9 | NC26 | 38.1 | 9140 or 9450 | 82.9 | 679 |
104.8 | NC31 | 50.8 | 9140 or 9450 | 100.4 | 914 |
114.3 | NC31 | 50.8 | 9140 or 9450 | 100.4 | 914 |
120.6 | NC35 | 50.8 | 9140 or 9450 | 114.7 | 965 |
127 | NC38 | 57.2 | 9140 or 9450 | 121 | 965 |
139.7 | NC40 | 57.2 | 9140 or 9450 | 132.2 | 1067 |
158.8 | NC46 | 71.4 | 9140 or 9450 | 144.5 | 1067 |
168.3 | NC50 | 71.4 | 9140 or 9450 | 154.8 | 1168 |
177.8 | NC50 | 71.4 | 9140 or 9450 | 164.7 | 1168 |
196.8 | NC50/NC56 | 71.4 | 9140 or 9450 | 185.3 | 1626 |
203.2 | NC56/6 5/8REG | 71.4 | 9140 or 9450 | 190.1 | 1727 |
209.6 | 6 5/8REG | 71.4 | 9140 or 9450 | 195.6 | 1727 |
215.9 | 6 5/8REG | 71.4 | 9140 or 9450 | 195.6 | 1727 |
228.6 | 6 5/8REG | 71.4 | 9140 or 9450 | 212.7 | 1829 |
241.3 | 7 5/8REG | 76.2 | 9140 or 9450 | 223.8 | 1829 |
254 | 7 5/8REG/8 5/8REG | 76.2 | 9140 or 9450 | 237.3 | 1930 |
279.4 | 8 5/8REG | 76.2 | 9140v9450 | 266.7 | 2032 |
2. Non-Magnetic Drill Collar Mechanical Property
Fishing Neck OD | Yield Strength Rf(MPa) | Tensile Strength Rm(MPa) | Elongation Ali(%) | Reduction of Area (%) | Impact Value (Joule) | Hardness HB |
3 1/2”-6 7/8” | ≥758 | ≥827 | ≥18 | ≥45 | ≥81J(RT) | 285~341 |
7”-11” | ≥689 | ≥758 | ≥20 | ≥45 | ≥81J(RT) | 285~341 |
* relative permeability: μ(Gauss/Oersted)<1.010
* magnetic fieldgradient: Max. Deviation of the Magnetic field in the inner hole to uniform magnetic field: ≤±0.05μT
* intergranular corrosion(Anti corrosion): as per ASTM A262E for intergranular corrosion test.
