Oilfield Handling tools API 7K ZQ series Power Tong/Hydraulic Drill Pipe Power Tongs for Oil Well Drilling with High Quality
ZQ Drill Pipe Power Tong is an ideal well head tool for oil drilling, widely applied for making-up and breaking-out in offshore and onshore drilling operations and well servicing operations. The drill pipe tong features safety, labor-saving, and high-efficiency. Open-throat design of the ZQ series allows the tongs to escape from drilling pipe freely with high mobility. The tong is a combination of spinning tong and torque tong. It substitutes cathead, manual tong and rotary rope in making-up and breaking-out. The tongs are designed and manufactured according to API Spec 7K Specification for Drilling Equipment.
Type |
ZQ203-125 |
ZQ162-50II |
ZQ203-100II |
ZQ203-100III |
ZQ203-125II |
ZQ203-125III |
|
|
Size tange |
mm |
127-203 |
85-162 |
127-203 |
127-203 |
127-203 |
127-203 |
in |
3-1/2”coupling, 8” body |
2-3/8”coupling, 5”coupling |
3-1/2”coupling, 8 ”body |
3-1/2”coupling, 8 ”body |
3-1/2”coupling, 8” body |
3-1/2”coupling, 8 ”body |
|
|
Max. torque |
kn.m |
125 |
50 |
100 |
100 |
100 |
100 |
ft.lbf |
92200 |
36880 |
7350 |
7350 |
92200 |
92200 |
|
Speeding (High gear) |
rpm |
40 |
60 |
40 |
40 |
40 |
40 |
|
Spending (Low gear) |
2.7 |
4.1 |
2.7 |
2.7 |
2.7 |
2.7 |
2.7 |
|
Air pressure |
Mpa |
0.5-1 |
|||||
Psi |
72-144 |
||||||
|
Pressure rating |
Mpa |
20 |
16 |
16.6 |
16.6 |
20 |
20 |
Psi |
2900 |
2320 |
2400 |
2400 |
2900 |
2900 |
|
|
Flow rating |
L/min |
114 |
120 |
114 |
114 |
114 |
114 |
gpm |
30 |
31.7 |
30 |
30 |
30 |
30 |
|
|
Shifting distance |
mm |
1500 |
1000 |
1500 |
- |
1500 |
- |
in |
59 |
39.4 |
59 |
- |
59 |
- |
|
|
Travel distance |
mm |
- |
- |
- |
0-2000 |
- |
0-3000 |
in |
0-78.5 |
0-118 |
|||||
|
Lifting distance |
mm |
- |
0-440 |
0-485 |
0-800 |
0-485 |
0-800 |
in |
0-17.3 |
0-17 |
0-31.5 |
0-17 |
0-31.5 |
||
|
Size |
mm |
1785*1080*1360 |
1570*800*1370 |
1760*1000*1630 |
1760*1650*2050 |
1760*1080*1630 |
1785*1740*2050 |
in |
70*42*53 |
62*31*54 |
69*39*64 |
69*65*81 |
70*42*64 |
70*68.5*81 |
|
|
Weight |
Kg |
2650 |
1700 |
2500 |
3250 |
2750 |
3700 |
lb |
5840 |
3748 |
5510 |
7165 |
6063 |
8160 |
|
