Oil drilling equipment API 7-1 Drill Stabilizer forging for drill rod/Oil and Gas forged integral spiral blade stabilizer in BHA
1. API 7-1 non-magnetic stabilizer and drilling stabilizer
2. Non-magnetic stabilizer
3. Standard: API Spec.7
4. Specifications: OD of Bit: 6"-42"
5. Material: AISI 4145H/ AISI 4145H MOD/ AISI 4340/ AISI4140-4142/ Non-mag material
6. Hardfacing: HF1000, HF2000, HF3000, HF4000, HF5000
Size (Code) Inch | Connection Inch | Fishing Neck Inch | Overall Length Inch | Fishing Neck Length Inch | Blade Length Inch | Blade Width Inch |
42" | 8-5/8"REG | 11" | 120" | 32” | 24” | 6.5” |
36" | 7-5/8"REG | 9.5" | 110" | 30” | 22” | 6.5” |
26" | 7-5/8"REG | 9.5" | 100" | 30” | 20” | 4” |
17 1/2" | 7-5/8"REG | 9.5" | 90" | 30” | 18” | 3.5” |
12 1/4" | 6-5/8"REG | 8 " | 90" | 30” | 18” | 3” |
8 1/2" | 4 1/2”IF | 6 3/4" | 72" | 28” | 16” | 2.25” |
6" | 3-1/2”IF | 4 3/4" | 66" | 28” | 16” | 2” |
