Help CenterAPI 7-1 Drilling Stabilizer, Integral Blade Stabilizer up to 42'' HF1000~5000, Non-magnetic Stabilizer
Related Products
-
API AISI 4145H Mod Drill Stabilizer, Integral Spiral and Straight Blade Stabilizer, Oil and Gas BHA Oil Downhole Drilling ToolsUS$ 1,000 - 15,000MOQ: 1 Piece -
Oil Field Drilling AISI 4145H Mod Integral Blade Stabilizer/API 7-1BHA Downhole Drill StabilizerUS$ 1,000 - 15,000MOQ: 1 Piece
-
Oil Field Drill Stabilizer, API AISI 4145H Mod Integral Blade Stabilizer, Oil and Gas BHA Oil Downhole ToolsUS$ 1,000 - 15,000MOQ: 1 Piece
-
API Integral Blade Stabilizer of Oil Downhole Tools, AISI 4145H Mod Drill Stabilizer in Bottom Hole AssemblyUS$ 1,000 - 15,000MOQ: 1 Piece
-
Bottom Hole Assembly API 7-1 Drill Stabilizer Forging/BHA Forged Stabilizer in Oil and GasUS$ 500 - 10,000MOQ: 1 Piece
Integral blade stabilizer is an important tool in the drilling engineering to control the well deviation. It can stabilize the drilling tools in the drilling process of oil, gas and geological exploration. It can increase the bit life, drilling speed and well bore quality. There are two kinds of integral stabilizers: spiral integral blade stabilizer and straight integral blade stabilizer.
Material: AISI 4145H/AISI 4145H mod/AISI 4340/AISI4140-4142/Non-mag material
Hardfacing: HF1000, HF2000, HF3000, HF4000, HF5000
|
Size (Code) Inch |
Connection Inch |
Fishing Neck Inch |
Overall Length Inch |
Fishing Neck Length Inch |
Blade Length Inch |
Blade Width Inch |
42" |
8-5/8"REG |
11" |
120" |
32” |
24” |
6.5” |
36" |
7-5/8"REG |
9.5" |
110" |
30” |
22” |
6.5” |
26" |
7-5/8"REG |
9.5" |
100" |
30” |
20” |
4” |
17 1/2" |
7-5/8"REG |
9.5" |
90" |
30” |
18” |
3.5” |
12 1/4" |
6-5/8"REG |
8 " |
90" |
30” |
18” |
3” |
8 1/2" |
4 1/2”IF |
6 3/4" |
72" |
28” |
16” |
2.25” |
6" |
3-1/2”IF |
4 3/4" |
66" |
28” |
16” |
2” |
