3d cnc wood carving router maxicam used 1325/1530/2030/2040
Technical parameters: | |||
Model |
1325 ATC |
||
FOB QingDao price |
$13254 |
||
X,Y,Z working area |
1300*2500*200mm |
||
Drive motors |
Inovance servo motor |
||
spindle |
5.5kw atc water cooled spindle |
||
Inverter |
Delta |
||
Machine table |
Table surface-bakelite combined Aluminum T -slot extrusion, vacuum table |
||
Vacuum pump |
5.5kw |
||
Tool magezine |
Linear 6 pcs with oil system |
||
X, Y, Z Travelling Potioning Accuracy |
±0.02/300mm |
||
X, Y, Z Travelling Repositioning Accuracy |
±0.02mm |
||
Frame |
Big thickened Steel Square Tubes, thickness up to 8mm |
||
X, Y structure |
Rack and pinion drive, Hiwin square rail linear bearing 20mm |
||
Z axis structure |
Germany imported ballscrew and Hiwin square linear rail 20mm |
||
Max Rapid Travel Rate |
32,000mm/min |
||
Max working speed |
20,000mm/min |
||
Working voltage |
AC380V, 60Hz/50hz, 3 phase |
||
Command languages |
G code |
||
Control system |
NCSTUDIO control system with handwheel |
||
Limit stop |
Omron Hard limit stop and electronic limit stop |
||
Cutter diameter |
3.175-12.7mm |
||
Automatic tool change time |
8 seconds |
||
Dust collector |
Yes |
||
Package size |
3.1*2.25*1.8m |
||
package |
In one wooden case |
||
Gross weight |
1500kg |
||
Net weight |
1300kg |
||
PS:The machine parts can be changed or upgrade | |||
spare parts for free |
Qty |
Unit |
|
Cutting tools |
10 |
pcs |
|
clamp |
8 |
pcs |
|
spanner |
2 |
pcs |
|
Power Cord |
1 |
pcs |
|
Brush |
1 |
pcs |
|
Sealing Strip |
20 |
meters |
|
Collet |
2 |
pcs |
|
CE Standard
1300*2500*200mm
9.0KW HSD air cooling spindle (world most famous brand, advanced technology and good performance)
Heavy duty body (8mm welded steel structure, with high temperature quenching and aging treatment)
X, Y gear transmission, Z Taiwan TBI ball screw transmission (fantastic accuracy)
Taiwan Hiwin 25 rails
Vacuum table and cacuum pump
Taiwan Syntec control system (world famous brand, fast speed and fantastic performance)
Japan YASKAWA servo motor and driver (world most famous brand, advanced technology, good performance)
Delta inverter
Filter
Tool sensor (high efficiency)
Auto tool height sensor
Q: Are you a manufacturer or trading company?
A: We are a Manufacturer and enjoying independent R&D team for 10 years.
Q: Do you have after-sale service team?
A: 24 hours online service for you, via tel/email/video or other way you prefer.
Q: Is there any inspection before delivery?
A: Strict quality examine before delivery, qualified industry related standard requirement.
Q: Can you offer customize manufacture?
A: Customize available based on your demands.
