wood carving cnc router auto tool changer with japanese motor driver

Technical parameters:

Model

1325 ATC

FOB QingDao price

$13254

X,Y,Z working area

1300*2500*200mm

Drive motors

Inovance servo motor

spindle

5.5kw atc water cooled spindle

Inverter

Delta

Machine table

Table surface-bakelite combined  Aluminum T -slot extrusion, vacuum table

Vacuum pump

5.5kw

Tool magezine

Linear 6 pcs with oil system

X, Y, Z Travelling Potioning Accuracy

±0.02/300mm

X, Y, Z Travelling Repositioning Accuracy

±0.02mm

Frame

Big thickened Steel Square Tubes, thickness up to 8mm

X, Y structure

Rack and pinion drive, Hiwin square rail linear bearing 20mm

Z axis structure

Germany imported ballscrew and Hiwin square linear rail 20mm

Max Rapid Travel Rate

32,000mm/min

Max working speed

20,000mm/min

Working voltage

AC380V, 60Hz/50hz, 3 phase

Command languages

G code

Control system

NCSTUDIO control system with handwheel

Limit stop

Omron Hard limit stop and electronic limit stop

Cutter diameter

3.175-12.7mm

Automatic tool change time

8 seconds

Dust collector

Yes

Package size

3.1*2.25*1.8m

package

In one wooden case

Gross weight

1500kg

Net weight

1300kg

PS:The machine parts can be changed or upgrade

spare parts for free

Qty

Unit

Cutting tools

10

pcs

clamp

8

pcs

spanner

2

pcs

Power Cord

1

pcs

Brush

1

pcs

Sealing Strip

20

meters

Collet

2

pcs
