Automatic Liquid Filling and Sealing Machine Enjoying Excellent Fame

Specifications

liquid filling and sealing machine, filling machine,filling and sealing line

Brief introduction

1. 8 head linear filling and sealing machine is widely used in the field of pharmaceutical, food, chemical and pesticide. It is used for filling of liquid, paste and other fluid. It adopts linear filling, rotary sealing and double position capping. It is compact, reasonable and can join with other equipment to make a line.

2. Stainless steel piston pump volumetrically filling, mechanical transmission, accurate, gently, rotary valve type, no bottle, no filling.

3. Double position rotary capping machine is specially designed for high speed requirement.

Main technical Parameters:

a)      speed: 60-80b/min

b)      filling precision≤±2%

c)      cap loading rate≥99%

d)      cap screwing rate≥99%

e)      power380V/50Hz

f)       air consumption0.60.8MPa/0.4m³/h

g)      power consumption8 head filling and sealing machine1.7Kw

            1.4 Kw

h)      dimensionrotary valve type2400×860×1900

               double position rotary capping machine2200×1200×1500

i)       weightrotary valve type700Kg

            double position rotary capping machine500 Kg
