Specifications
SM Big Volume Pillow Pack Vertical Packing Machine1. high quality
2. easy operation
3. low price and good after-service
SM Big Volume Pillow Pack Vertical Packing Machine
Standard Features:
1. The machine can automatically complete the products measuring, conveying and feeding, filling and bag forming, date code printing, bag sealing and cutting.
2. Servo-motor driven, twin belt bag pulling system.
3. High sensitive fiber optic photo sensor can automatically trace color mark accurately.
4. PLC control system combined with touch screen, can easily set can change the packing parameters. Daily production output and self-diagnostic machine error can be viewed directly from the screen.
5. PID temperature controller monitors heat sealing temperature within ±1.
6. Automatic edge position control assures consistent film alignment during production to produce uniform bag quality.
7. Selected electrical and pneumatic components from reliable international manufacturer.
8. With CE Certificate
Necessary Measuring Filler:
1. Auger Screw Filler for Powder
2. Multi-head weigher for granule
3. Linear Weigher for Granule
4. Rotary Gear Pump for Liquid
5. Piston Pump for Liquid
Optional Parts for Main Machine:
1. Gusset Pouch forming Device
2. Date Code Printer
3. Sachet header Hole Puncher
4. Fix Number Cut
5. Stainless Steel Machine Out Case
Technical Specification:
Model No. |
PM-720 |
PM-620 |
PM-520 |
PM-420 |
Max. Measuring Range (ml) |
4000 |
3000 |
2000 |
1000 |
Bag Length (mm) |
200-500 |
120-450 |
80-390 |
80-300 |
Bag Width (mm) |
150-350 |
110-300 |
90-250 |
80-200 |
Film Width(mm) |
320-720 |
240-620 |
200-520 |
160-420 |
Speed (Bag/min) |
10-30 |
10-35 |
15-40 |
15-50 |
Power |
220V/1ph, 3.5Kw |
220V/1ph, 3.2Kw |
220V/1ph, 2.8Kw |
220V/1ph, 2.5Kw |
