Product Details
| Design | Two Post | Type | Double Cylinder Hydraulic Lift | |
| Certification | CE | Lifting Capacity | 3.5 Ton | |
| Lifting Height(mm) | 1834mm | Overall Width(mm) | 3433mm | |
| Place of Origin | Jiangsu, China | Brand Name | TORIN | |
| Model Number | QJY235D-E | Warranty | 1 Years |
Product Description
Description
Torin BigRed 3.5T two post hydraulic lift
| Model | QJY235D-E |
| Capacity | 3500 kg |
| Stroke | 1834 mm |
| Overall Height | 3764 mm |
| Overall Width | 3433 mm |
| Drive Through Clearance | 2572 mm |
| Switchoff Level | 3616 mm |
| Support Bracket Length Min. | 770 mm |
| Support Bracket Length Max. | 1105 mm |
| Plate Height Min. | 114 mm |
| Plate Height Max | 154 mm |
| Column Spacing, Interior Dimension | 2862 mm |
| Motor Performance | 2.2 kw |
| Electrical Connection | 380/220v |
| Lifting Time | 50 sec. |
| G.W. | 705 kg |
Package Size
Qty/20" (15pcs) | 1# 3650*720*470 mm 1# 760*230*330 mm 3# 590*240*250 mm |
**100% Factory Inspection**
1. Fully automatic electric control panel;2. Driven by dual hydraulic cylinders;3. Chain type lifting system;4. Internal Electric locking mechanism, w/two point safety latches in each column;5. Automatic safety asTrm locks;6. Easy to operate up and down switches on electrical control box;7. Steel wire rope equalizing cables;8. Multi-voltage power supply is available for electrical requirements;9. Optional motors available;10. Adjustable lift pads and adapters;11. Duable power coat finish;12. No floorplate restrictions;13. Overhead crossover beam.
