bafang SWXH6 CST rear hub motor (RM G12.250.DC )
This rear-drived motor ,which is compatible with the disc brake ,has a ralated power of 250W ,a reduction ratio of 1:6:3 and a maximun torque of 32N.M providing ideal power for vehicles ,strong and efficient .
---------------------------------------------------------------------------------------
Position : rear motor
Contruction : Gear motor
Normail Voltage 24/36
Rated power :250W
RPM : 265~325
Max torque : 80N.M
Efficiency : more than 80%
Mounting parameter
-----------------------------------------------------------------------------------
Brake : Disc brake
Weight : 3.2KGS
Installation width: 135mm
Max Housing Diameter : 136mm
Cabling : Shaft Center ,left
Gearshift : Cassette
Spoke specification : 12 G /13G
-------------------------------------------------------------------------------------------------------------------------------------
Further Specification
Cadence ( pulses/cycle) 6/1
Reduction Ration : 1:6;3
Magent Poles : 20
Noise : less than 55 dB
Hall sensor : Opitional
Connector : waterproof
-----------------------------------------------------------------------------------------------------------------------------------
Test & Certifiation
IP-code : IP 65
Certifications : ROHS /CE
1, This kits can be installed on standard normal bike frame easily, no need to change the frame.
advantage of this kits
2, High starting torque, Max torque≥80N, good performance on climbing.
3, Double clutch is used on drive unit, more safety.
4, High efficiency, low consumption, long travel distance.
