Home > Electrical & Electronics > Breaker & Protector > Circuit Breaker > BDM12-63 NEW MINI CIRCUIT BREAKER
BDM12-63 NEW MINI CIRCUIT BREAKER
US$ 0.4 - 0.8
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
BODUN
Model Number:
BDM12-63
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Wenzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
BDQO1 CH BREAKER 2P 100A PLUG-IN FUSE BREAKERUS$ 1.86 - 1.96MOQ: 100 Pieces -
BDQO1 CH BREAKER 2P 70A PLUG-IN FUSE BREAKERUS$ 1.86 - 1.96MOQ: 100 Pieces
-
BDQO1 CH BREAKER 2P 60A PLUG-IN FUSE BREAKERUS$ 1.86 - 1.96MOQ: 100 Pieces
-
BDQO1 CH BREAKER 2P 50A PLUG-IN FUSE BREAKERUS$ 1.86 - 1.96MOQ: 100 Pieces
-
BDQO1 CH BREAKER 2P 40A PLUG-IN FUSE BREAKERUS$ 1.86 - 1.96MOQ: 100 Pieces
Place of Origin
Zhejiang, China
Brand Name
BODUN
Model Number
BDM12-63
Type
Mini
Poles Number
1
Specifications
1,New Model With Indicator.2,IEC60898
3,Certificates approval.
BDM12-63 MCB ( Miniature Circuit Breaker )
| Construction and Feature |
| Protection against both overload and short circuit High short-circuit capacity Easy mounting onto 35mm DIN rail |
| Technical Data |
| Pole No:1,1P+N,2,3,3P+N,4 Rated voltage:AC 230/400V Rated current(A):1,2,3,4,6,10,13,16,20,25,32,40,50,63 Tripping curve:B,C,D Ultimate short-circuit capacity(lcu):6KA Rated frequency:50/60Hz Energy limiting class:3 Rated impulse withstand voltage:6.2KV Electro-mechanical endurance:4000 Connection terminal:Pillar terminal with clamp Connection capacity:Rigid conductor up to 25mm2 Fastening torque:2.0Nm Installation: On symmetrical DIN rail 35mm Panel mounting Terminal Connection Height:21mm |
