CJ19 AC CONTACTOR FOR POWER FACTOR CORRECTION

Name: CJ19 AC CONTACTOR FOR POWER FACTOR CORRECTION
Brand: BODUN
SKU: 129706131
Availability: InStock

Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

BODUN

Model Number:

CJ19

Yueqing BODUN Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo/Wenzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name BODUN

Model Number CJ19

Electricity Type AC

Number of Pole 4

Specifications

1.Conforms to IEC60947-4-1
2.For power Factor Correction
3.380V,50/60Hz

CJ19 AC Contactor

Electrical life			CJ19-25C	CJ19-32C	CJ19-43C	CJ19-63C	CJ19-95C
Rating current le(380V)A			100	100	29	100	100
Power of controlled capacitor		220/230V	17	23	10	43	63
Power of controlled capacitor		380/400V	6	9	20	15	22
Rating insulation voltage(V)			12	18	500	30	40
Rating operational voltage(V)			380
Restrained surge capacity			20le
Operation range			Pick-up:(85%-110%);Drop-out::(20%-75%) Us
Coil power(VA)	Start-up		70	110	110	200	200
Coil power(VA)	Holding		8	11	11	20	20
Control capacity of auxiliary contact			AC-15 360VA;DC-13 33W
Weight(Kg)			0.44	0.63	0.64	1.4	1.5

Outline and mounting dimension
Type	Amax	Bmax	Cmax	Dmax	E	F	Note
CJ19-25C	80	47	124	76	34/35	50/60	Screw mount/35mm rail mount
CJ19-32C	90	58	134	86	40	48
CJ19-43C	90	58	136	86	40	48
CJ19-63C	132	79	150
CJ19-95C	135	87	158
