CJ19 AC CONTACTOR FOR POWER FACTOR CORRECTION
- Ningbo/Wenzhou
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | BODUN | |
| Model Number | CJ19 | Electricity Type | AC | |
| Number of Pole | 4 |
Product Description
Specifications
1.Conforms to IEC60947-4-12.For power Factor Correction
3.380V,50/60Hz
CJ19 AC Contactor
Electrical life | CJ19-25C | CJ19-32C | CJ19-43C | CJ19-63C | CJ19-95C | ||
Rating current le(380V)A | 100 | 100 | 29 | 100 | 100 | ||
Power of controlled capacitor | 220/230V | 17 | 23 | 10 | 43 | 63 | |
380/400V | 6 | 9 | 20 | 15 | 22 | ||
Rating insulation voltage(V) | 12 | 18 | 500 | 30 | 40 | ||
Rating operational voltage(V) | 380 | ||||||
Restrained surge capacity | 20le | ||||||
Operation range | Pick-up:(85%-110%);Drop-out::(20%-75%) Us | ||||||
Coil power(VA) | Start-up | 70 | 110 | 110 | 200 | 200 | |
Holding | 8 | 11 | 11 | 20 | 20 | ||
Control capacity of auxiliary contact | AC-15 360VA;DC-13 33W | ||||||
Weight(Kg) | 0.44 | 0.63 | 0.64 | 1.4 | 1.5 | ||
Outline and mounting dimension | |||||||
Type | Amax | Bmax | Cmax | Dmax | E | F | Note |
CJ19-25C | 80 | 47 | 124 | 76 | 34/35 | 50/60 | Screw mount/35mm rail mount |
CJ19-32C | 90 | 58 | 134 | 86 | 40 | 48 | |
CJ19-43C | 90 | 58 | 136 | 86 | 40 | 48 | |
CJ19-63C | 132 | 79 | 150 |
|
|
| |
CJ19-95C | 135 | 87 | 158 |
|
|
| |
