WD67K HYDRAULIC TORSION SERVO CNC PRESS BRAKE WITH BACKGAUGE

WD67K HYDRAULIC TORSION SERVO CNC PRESS BRAKE WITH BACKGAUGE thumbnail-1
WD67K HYDRAULIC TORSION SERVO CNC PRESS BRAKE WITH BACKGAUGE photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Anhui, China
Brand Name:
HUDUAN
Contact Supplier Request Quote Chat Now
Maanshan Hudong Heavy Industry Machinery Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Anhui, China
Brand Name HUDUAN
Model Number 63T/3200
Machine Type Press Brake
Raw Material Sheet / Plate Rolling
Material / Metal Processed Carbon Steel
Power Cnc
Automation Automatic
Extra Services Cut To Length
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

ATOS valve group
Gear pump
Pipe joint(not welded)
E10-D NC system
Whole processing

WD67K HYDRAULIC TORSION SERVO CNC PRESS BRAKE WITH BACKGAUGE



1:Professional Manufacture
2:Good Quality with ISO
3:Competitive Price
4:Over 30 years experience





 Hydraulic press brake with E18 NC control

No.

Name

Brand

Location

1

Motor

Dangpeng

Zhenjiang, China

2

Electrics

TE/OMROM

Germany brand

3

Oil Cylinder

Wuyang

Maanshan, China

4

Seal ring



DZ

Taiwan

5

Pump

Hangfa

Shanghai, China

6

Hydraulic system

Omega

Jining, China

7

Two axes Controller

E200

Estun,China

8

Punch and Die

Xinming / Lianmeng

Maanshan, China

9

Pipe connector

EMB

Germany

10

Foot Switch

Karcon

South Korea

11

Ball lead screw

HIWIN

Taiwan

12

Straight-line guide

HIWIN

Taiwan



Model: WF125T/3200

No



Name

Amount

Unit

1

Nominal pressure

1250

KN

2

Poles distance

2 600

mm

3

Throat depth

320

mm

4

Slipper stroke

120

mm

5

Max. opening height

380

mm

6

Slipper stroke adjustment

100

mm

7

Diameter of cylinder

200

mm

8

Main motor power

7.5

kw

9

Oil pump power

25

ml/r

10

System pressure

22

Mpa

11

Wallboard thickness

50

mm

12

Slipper thickness

50

mm

13

Machine weight

7 500

Kg

14

Workbench length

3 200

mm

15

Dimension (LxWxH)

3 200x1 750x2 520

mm
