Help CenterSoft Ferrite Cores
Related Products
Specifications
1.high power ferrite core2. low loss Ferrite core
3.large size
4.Material PC40 ,PC44 ,PC95
5.can process to different size
Le=375mm ,Ae=1225mm2 .
material : PC40 ,PC44 ,PC95
high power large size soft Mn-Zn ferrite cores.
transformer ferrite cores.
1.High Saturation material, low cost &high efficiency
2.wide inductance range, high current capability low magnetic leakage
3.low DC resistance,good control on noise due to the toriodal constructure
4.Characteristics:Small volume, Big current output, Excellent current choking performance.
5.Various material available to meet different frequency requirements
Material: PC40 PC44
Applications:
Transformer, induction heating, inverter welding machine.Plating Power Supply, Ozone generator
Parameter |
Symbol |
Value |
Unit |
Core constant |
C1 |
0.44 |
mm-1 |
Effective path length |
Le |
504 |
mm |
Effective area |
Ae |
1160 |
mm2 |
Effective volume |
Ve |
593600 |
mm3 |
Inductance factor |
AL |
6000 |
nH/N2 |
Weight of set |
W |
2840 |
g |
Other name |
UU130 UU130/91/40 |
||
Product code |
S/N |
S/N:P03160197 |
|
SGS certificate:
